KYN28A Metal Enclosed Drawout Switchgear IP4X Protection Level Enclosure
KYN28A Metal Enclosed Drawout Switchgear IP4X Protection Level Enclosure
Specifications
Rated Short-Term Withstand Current :
40kA / 4s
Protection Level (Enclosure) :
IP4X
Packaging Details :
Different packaging methods are adopted according to different modes of transportation
Rated Peak Withstand Current :
100kA
Brand Name :
EUE Power
Place of Origin :
China
Rated Voltage :
24kV
Price :
Negotiable
1min Power Frequency Withstand Voltage (Alternately And Oppositely) :
42/50
Payment Terms :
L/C,T/T,DDP,DDU
Lightning Impulse Withstand Voltage (Alternately And Oppositely) :
95kV
Rated Frequency :
50Hz
Rated Current Of Main Bus :
4000A
Product Name :
KYN28A Metal-Enclosed Drawout Switchgear
Description

KYN28A-12/24 Metal-Enclosed Drawout Switchgear

The KYN28A-12/24 Metal-Enclosed Drawout Switchgear is engineered for high-performance power receiving, distribution, and control. Designed for three-phase AC 50 Hz, 3.6–24 kV systems, it ensures robust operation in both single-busbar and single-busbar sectionalized configurations.

  • ✅ Fully Metal-Clad Design: Enhanced safety with IP4X enclosure rating.
  • ✅ Reliable Performance: Internal arc fault withstand capability for maximum protection.
  • ✅ Safety Interlocks: Equipped with comprehensive mechanical interlocks meeting five-prevention requirements.

Application

The product provides reliable power receiving, distribution and control, and is suitable for power plants, generator transmission systems, industrial and mining enterprises, secondary substations and high-voltage motor starting applications.

Performance Advantages

  • Rational construction: The switchgear adopts a fully metal-clad design with an IP4X enclosure rating. Power and control cable openings are sealed with rubber rings to prevent dust and small animals from entering, protecting circuit insulation.

  • Stable and reliable: Observation windows on the circuit breaker and cable compartment doors allow easy checking of breaker position, status, and cable operation. The switchgear also maintains internal arc fault withstand capability.

  • Superior performance: Each of the three compartments is equipped with a pressure relief channel to release pressure caused by internal arc faults.
  • High protection level: The switchgear is equipped with reliable mechanical interlocks and comprehensive anti-misoperation measures, meeting the power system’s five-prevention requirements.
  • Easy to expand: The cable compartment provides sufficient space for cable connection, allowing two parallel cable groups per phase. Voltage transformers, surge arresters and other components can also be installed as required.
  • Good suitability: The cable compartment provides sufficient space for cable connection, allowing two parallel cable groups per phase. Voltage transformers, surge arresters and other components can also be installed as required.

Product Photos

KYN28A Metal Enclosed Drawout Switchgear IP4X Protection Level Enclosure

Technical Parameters

Parameter Unit Value
Rated Voltage kV 12/24
Rated insulation level 1min power frequency withstand voltage Alternately and Oppositely kV 42/50
Isolation Fracture kV 48/65
Lightning impulse withstand voltage Alternately and Oppositely kV 75/95
Isolation Fracture kV 85/110
Rated Frequency Hz 50
Rated Current of Main Bus A 630, 1250, 1600, 2000, 2500, 3150, 4000
Rated Current of Branch Bus A 630, 1250, 1600, 2000, 2500, 3150, 4000
Rated Short-term Withstand Current kA 16, 20, 25, 31.5, 40
Rated Peak Withstand Current kA 40, 50, 63, 80, 100
