Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay
Specifications
Brand Name :
MESTECHS
Model Number :
SHP100-H
Place of Origin :
CHINA
MOQ :
2
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000pcs/Month
Packaging Details :
Command package
Delivery Time :
45 work days
Size :
68mm X 46mm X 23.5mm
Consumption :
Less Than 1.2W
Power Input :
85~305VAC Or 120~432VDC
Working Temperature :
-40°c To +70°c
Distance :
point to point up to 1500m
Relay mode :
support 10 levels relay
Description

SHP100-H Long range power line communication cable extender module relay mode

SHP100-H is a power line carrier communication module suitable for industrial application. Its HD-PLC technology conforms to IEEE 1901 (* 2) international standard and ITU-T g.9905 multi hop technology for relay function.SHP100-H uses OFDM modulation technology, the modulation frequency band can be up to 2-28mhz. The long-distance communication rate can reach several Mbps.

As a simple and easy-to-use Ethernet transmission module, SHP100-H can shorten the development cycle and reduce the design threshold for users. The module provides a set of Ethernet interface and a 12V DC output (output power can be up to 5W). Users can easily transmit data on the power line (220V AC power line) through the module.

SHP100-H (HD-PLC Technology) has the following advantages over Homeplug AV technology

SHP100-H Homeplug AV
Point to point maximum transmission distance (power line) 1.5km (within 1.2km recommended) 700m (within 500m recommended)
Point to point maximum transmission distance (coaxial cable) 2km (within 1.5km recommended) 800m (within 600m recommended)
Maximum number of single network slave nodes 512 16
Relay mode Support 10 level relay and automatic routing Relay not supported
Minimum power consumption 1.2W 2.5w
Modulation frequency Full frequency or half frequency Fixed 2-28mhz
Working temperature -40℃~70℃ -20℃~50℃

Electrical characteristics

Functional Characteristics
Power line interface Modulation Mode
Wavelet-OFDM
Modulation Band
2~28MHz
Physical layer / effective transmission rate Up to 240Mbps/92Mbps
Error Correction Method Convolutional code and Solomon code
Encryption Method
AES-128bit
LAN Interface Standard
IEEE 802.3/IEEE 802.3u
Communication Mode
10Base-T/100Base-TX
Performance Parameter working Temperature
-40℃~+70℃
Working Humidity
20%~85%
Size
68 X 46 X 23.5 mm
Power Supply
85~305VAC or 120~432VDC

Portable Ethernet Cable Extender 68mm X 46mm X 23.5mm Support 10 Levels Relay

Order Information

Product Description Order Code

Ethernet Cable Extender SHP100-H
