Specifications
Brand Name :
MESTECHS
Model Number :
MPL80-F-2
Place of Origin :
CHINA
MOQ :
2
Price :
Negotiable
Supply Ability :
1000 pieces /Month
Packaging Details :
Common Package
Payment Terms :
T/T
Delivery Time :
35 work days
Warranty :
1 Year
Product name :
100M Ethernet Extender
Transmission distance :
500m/1600ft
Weight :
160g
Small size :
100X74X26mm
Application :
Railway,Coal mine，fishing
Description

Ethernet Network Extender MPL80-F-2 Ethernet on AC or DC Powerline long range 500m high speed 95Mbps

  • MPL80-F-2 network extender is a high-speed cable network transmission equipment. Based on OFDM modulation and demodulation technology, it can be transmitted by any AC or DC power line. The maximum transmission distance can reach 500 meters (1 mm diameter Coaxial cable), and the maximum physical layer rate can reach 240 Mbps.
  • Electric power and data are transmitted on the same cable.
  • Power supply, signal common cable transmission, easy construct, cost savings;
  • Support point to point and point to multi-point data transmission.
  • The power consumption of the whole machine is less than 2W.
  • Compliance with EU EN-50561 Standard and Specification.

Typical application:

Industrial video surveillance

Elevator swipe control management system

Ethernet Extender on Power line

MPL80-F-2 can support point-to-point communication and can also support point to multi-point communication of bus structures.

Point to point.

High Speed 95Mbps Ethernet Cable Extender , Network Cable Extender Long Range 500m

Point to multi-point

High Speed 95Mbps Ethernet Cable Extender , Network Cable Extender Long Range 500m

MPL80-F-2 Wiring diagram

High Speed 95Mbps Ethernet Cable Extender , Network Cable Extender Long Range 500m

Electrical Characteristics:

Category Item Parameter
Power Input AC 100V-300V DC 18V-72V
Transmission Power dissipation ≤2W
Transmission Medium Power lines
Communication distance up to 500m
Bandwidth up to 95Mbps(UDP)
Multicast Support for IGMP multicast protocol
Ethernet 10M, 100M Adaptive
Connector Power in(WAN) Junction seat(Distance 3.81 mm)
Ethernet (data) RJ45(1,2 and 3,6)
Network signal input and output Junction seat(Distance 3.81 mm)

Indicator Light

 PWR Power indicator. Turn on the power.
LNK Signal connection light, when the main slave device signal connection, when the main slave device is not connected
RJ45 yellow and green light Network communication indicator light, flashing when communicating

Appearance

 Size 100mm(not include master dialing switch) X 74mm(not include Hanging ears) X 26mm
Color gray
Weight 160 g

Environmental Requirements

 Operating temperature -40℃-70℃
Humidity 0-95%
Storage temperature -40℃-85℃

Order Information

P/N: MPL80-F-2

High Speed 95Mbps Ethernet Cable Extender , Network Cable Extender Long Range 500m
