R·G-255 Cyanide Free Acidic Zinc Nickel Alloy Plating Process Bright Zn Ni Plating Process
R·G-255 Cyanide Free Acidic Zinc Nickel Alloy Plating Process Bright Zn Ni Plating Process
Specifications
acid-base :
Acidic
MOQ :
25-30kg
Metal type :
Zinc-Nickel Alloy
Model Number :
R·G-255
characteristic :
Cyanide-Free
Payment Terms :
T/T
Delivery Time :
5-8 work day
Packaging Details :
25kg/drum
Place of Origin :
China
Brand Name :
AOBANG
Description

R·G-255 Cyanide-Free Alkaline Zinc-Nickel Alloy Plating Process

Product Features

  1. RG-255 is a cyanide-free alkaline zinc-nickel alloy plating process. The bright alloy coating contains 12–18% nickel and 82–88% zinc, suitable for both rack plating and barrel plating.
  2. This process produces corrosion-resistant coatings with various color options, whose performance exceeds the standards required by automotive manufacturers.
  3. Excellent throwing power and covering power; the alkaline electrolyte features low corrosivity.
  4. Forms electrolytic zinc-nickel alloy layers, applicable to long-term continuous sheet metal plating production.

Operating Technical Parameters

Item Working Range
Cathode Current Density (Rack Plating) 2.0–5.0 A/dm²
Cathode Current Density (Barrel Plating) 0.8–1.2 A/dm²
Voltage (Rack Plating) 5.0–10.0 V
Voltage (Barrel Plating) 12.0–18.0 V
Cathode Current Efficiency 50–60 %
Coating Deposition Rate Approx. 0.3 μm/min at 2 A/dm²
Anode Current Density 1–5 A/dm²
Anode Material Nickel-plated iron plate or electrolytic nickel plate
Anode / Cathode Area Ratio 2:1
Operating Temperature 20–27 ℃
Bath Purification Method Low-current electrolysis (0.1–0.2 A/dm²)
