R·G-258 Weak Acid Zinc Nickel Alloy Plating Easy To Manage Tank Fluid
R·G-258 Weak Acid Zinc Nickel Alloy Plating Easy To Manage Tank Fluid
Specifications
Model Number :
R·G-258
Type :
Weak Acid Zn-Ni Alloy Process
Payment Terms :
T/T
Boric Acid :
17-25 g/L
MOQ :
25-30kg
Potassium Chloride :
160-220 g/L
Packaging Details :
25kg/drum
Operating Temperature :
30-40 ℃
Cathode Current Density :
1-3 A/dm² (Rack), 0.2-1.5 A/dm² (Barrel)
pH Value :
5.2-5.7
Place of Origin :
China
Nickel Chloride :
105-158 g/L
Brand Name :
AOBANG
Delivery Time :
5-8 work day
Product Code :
R·G-258
Description
R·G-258 Weak Acid Zinc-Nickel Alloy Plating Process
Product Features

RG-258 is a weak acid zinc-nickel alloy plating process with nickel content of 12%–15%. It is specially applicable for:

  • Plating cast iron parts such as brake pads in automotive industry
  • Plating fasteners including screws, nuts and bolts
  1. Extremely high corrosion resistance, greatly improving the performance of conventional zinc coatings. Nickel content remains highly uniform across a wide current density range.
  2. Only mild complexing agents are used with no ammonia. Fast metal deposition initiation, excellent adhesion, high hardness and superior wear resistance.
  3. All additives of RG-258 fully comply with RoHS regulations, free of lead, cadmium, mercury, hexavalent chromium, PBB and PBDE.
  4. Suitable for rack plating and barrel plating.
Bath Formulation & Operating Parameters
Item Concentration Range
Nickel Chloride (NiCl₂·6H₂O) 105–158 g/L
Potassium Chloride 160–220 g/L
Boric Acid 17–25 g/L
RG-258 Complexing Agent 15–25 mL/L
RG-258 Buffer 50–80 g/L
RG-258 Throwing Agent 20–30 mL/L
RG-258 Brightener 8–15 mL/L
Operating Temperature (Rack Plating) 30–40 ℃
Operating Temperature (Barrel Plating) 25–35 ℃
pH Value 5.2–5.7
Cathode Current Density (Rack Plating) 1–3 A/dm²
Cathode Current Density (Barrel Plating) 0.2–1.5 A/dm²
Zinc / Nickel Anode Current Ratio 3:1 ~ 6:1
Deposition Rate (Rack Plating, 2.5 A/dm²) 0.5–0.8 μm/min
Deposition Rate (Barrel Plating, 1 A/dm²) 0.2–0.3 μm/min
