13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
13.0Mpa ACM Rubber Acrylic Elastomer PA515E For Oil Seal And Gasket
Specifications
Brand Name :
CHENGUANG FSP
Model Number :
PA-515E
Certification :
ISO9001
Place of Origin :
China
Polymer :
Acrylic Elastomer 515E
Typical Properties :
Excellent oil and heat resistance / Low compression set / Excellent curing properties
Physical Form :
Off-white to light yellow
Tensile strength :
13.1Mpa
Mooney Viscosity :
45 ML 1+10 @ 100℃
Volatile Matter :
≤1.0%
Elongation at break, % :
245%
Description

Acrylic Elastomer PA515E

Excellent Curing Properties 13.0Mpa Acrylic Elastomer PA515E for Oil Seal and Gasket

DESCRIPTION

Acrylic rubber's widespread use in the automotive industry is due to its resistance to engine and transmission oil as well as automatic transmission fluids (ATF). With an operating temperature range between -20°C and +150°C, the latest generation of this rubber, HT-ACM (high-temperature-resistant polyacrylate elastomers), offers long-term thermal stability up to 175°C. ACM is utilized in the production of engine and transmission seals, turbocharger hoses, O-rings, diaphragms, hose applications, and roller coverings.

SPECIFICATION

Physical Properties
Press cured:180℃ @ 10min, post cured: 180 ℃ @ 4hour
Hardness, Shore A
66
Tensile strength, Mpa
13.0
Elongation at break, %
195
Compression set, % 150℃@70h
20
Heat Resistance Properties
175℃@70h in air
Tb change, %
-23
Eb change, %
+19
Hs change, Point
+5
Fluid Resistance
150℃@70h in ASTM No.1 oil
Tb change, %
+3
Eb change, %
+25
Hs change, Point
+4
Volume Swell, %
-1.0

CHENGUANG FSP
Zeon
Denka
Dupont
Tohpe
PA500
AR12
A403
AR4940
PA600
AR14
A804
VAMAC G
AR5140
PA700
AR22
PA4510
4051
AR501L
PA4520
4051EP
PA4530
4052EP
AR540L
PA4540
4053EP
PA1020
AR72
AR825
PA1030
AR72LF
AR840

Further safety and handing guide, can follow the product’s Material Safety Data Sheet or consult us.

APPLICATION

It is a low to middle viscosity mooney carboxyl type acrylic elastomer, it was designed for low
compression and excellent heat resistance and oil resistance product. PA515E universally used for
oil seal and gasket,hoses etc..
PACKING INFORMATION
PA515E is packaged in paper bag. The weight is 20kg net per bag.
SAFETY AND HANDING
Store in well ventilated place.
  • Avoid eye contact.
  • Keep adequate ventilation during mixing or processing.
  • Wash thoroughly any contacted skin and clothing after handling.
