P20 Mould Steel (P20)
P20 Mould Steel (P20)
Specifications
Place of Origin :
shenzhen, China
Brand Name :
GSf
Certification :
SGS
Model Number :
P20
Description

P20 Mould Steel (P20)

I.Composition:

C

Si

Mn

Cr

Mo

Ni

0.37-0.42

0.20-0.40

1.40-1.60

1.80-2.10

0.15-0.25

0.40

II. Equivalent Grades:

GB

DIN

ASTM

JIS

3Cr2Mo

1.2311

P20

----

III.Size:

Round

Diameter

Length

10mm-600mm

2000mm-5800mm

Steel plate

Thickness

Width

Length

10-900mm

180-2200mm

1000mm-5800mm

IV. Applications:

Degree of hardness and the metallography structure are even, the cutting value

and the polishing performance are outstanding, can be harden by flame, plates

hardly chrome and nitriding. This mould steel can apply to general requirements

of the size of the plastic mould and can be operated by electric corrosion.


P20 Mould Steel (P20)P20 Mould Steel (P20)
