DC53 Tool Die Steel Mould Steel
DC53 Tool Die Steel Mould Steel
Specifications
Place of Origin :
shenzhen, China
Brand Name :
GSf
Certification :
SGS
Model Number :
DC53
Description
DC53 Tool Die Steel Mould Steel

1.good quality.
2.convenient transportation.
3.resonable price.

1:Delivery hardness:≤255HB

Delivery status: As Hot rolled/forged. Delivery condition: annealed

2 Chemical composition:

C

Si

Mn

Cr

M0

V

1.0

1.05

0.35

8.0

2.0

0.2

3:Specification :

Round bar

Diameter (mm)

Length (mm)

50~300

2000~6000

plate/sheet

Thickness (mm)

Width (mm)

Length (mm)

20~300

150~850

2000~6000

4:Steel Surface :

Steel Sharp

Surface treatment

Round bar

Black / Polished / Peeled / Turned

steel plate

Black / Milling / Machined

5: Applications

  • Suitable to make the punch dies or drawing dies which are complicated in shape and high in precision;
  • Suitable to make the clid-work dies formed by linear cutting;
  • Suitable high-speed punch head and cold forging dies;
  • Suitable to make the blanking dies and punching dies with a thickness over 6mm..

6:Features

  • Toughness is 1 times higher than SKD11 cold rolled sheel. If used for fabrication of complicated punch dies and drawing dies, the resistance to crack and edge breaking will be highly improved.
  • After high-temperature tempering of the die under 520-530°c, the hardness may still reach 60-62HRC, so that the risk of crack caused by residual stress will be reduced for linear cutting dies.
  • Suitable for surface hardening treatment for extended service life of the dies.DC53 Tool Die Steel Mould SteelDC53 Tool Die Steel Mould Steel
