Key Features
Features:
480TVL High Resolution
30X Optical Zoom
Focus Length: 3.3mm~99mm
Screen Menu
Line Control
RS-485 Control
Specifications
|
Specification |
|
Specification |
show |
|
Image Sensor |
|
Sensor Type |
Sony CCD |
|
Sensor Size |
1/4 Inch |
|
Signal System |
NTSC, PAL |
|
Horizontal Resolution |
480TVLine |
|
Lens (mm) |
3.3~99 |
|
Minimum Illumination (Lux) |
0.5 |
|
Physical/Environment |
|
Camera - Power Supply |
DC12V±10% |
|
Camera - Power Consumption (W) |
<6W |
|
Camera - Operate Temperature (℃) |
-10~50 |
|
Camera - Storage Temperature (℃) |
-20~60 |
|
Camera - Operating Humidity (%) RH |
10~90 |
|
Camera - Dimensions (L x W x D, mm) |
115 x 60 x 65 |
|
Camera - Additional Features |
|
Camera Type |
Box Camera |
|
Waterproof |
No |
|
S/N Ratio (dB) |
>50 |
|
Video Output |
BNC 1.0Vp-p 75Ω |
|
White Balance |
Automatic |
|
Backlight Compensation |
Automatic |
|
Automatic Gain Control |
On/Off |
|
Electronic Shutter |
1/50(1/60)~1/100000sec |
|
What's in the box |
|
What's in the box |
1 Indoor Camera, User Manual - English |
