OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-DHP97
Certification :
Meets or Exceeds Rma and Iso Standards
Place of Origin :
China
MOQ :
1
Price :
$55-$965
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
5789 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Name :
Discharge Hose Pipe
Size :
1/2inch ~ 20 inch
Working pressure :
< 25 Bars
Working temperature :
-30 to +120 ℃
Material of rubber :
NR, NBR, EPDM, CR and etc
Material of flange :
Q235b Carbon Steel Paint
Reinforcement layer :
High Tensile Steel Wire Spiral
Packing :
Plastic Belt Packing
Length of each unit :
< 50m
Color :
Black
Application :
Water Discharge, Irrigation, Construction, Mining
Feature :
Lightweight, Flexible, and Easy to Handle
Warranty :
36 Months
Description
Water Discharge Hose Heavy Duty Rubber Leak Proof And Reliable Strength
Product Overview

The ideal economical and lightweight solution for general water transfer, irrigation, dewatering, and construction site drainage. Designed for easy handling and maneuverability, this hose reduces worker fatigue and offers reliable, cost-effective performance for a wide range of low-pressure applications where extreme durability is not the primary concern.

Case Study: A large agricultural co-op in Thailand needed an affordable and easy-to-handle solution for irrigating hundreds of small plots. Our lightweight PVC hoses were easy for workers to move and reposition daily, and their low cost allowed the co-op to outfit all their operations without exceeding their budget.

OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge
OEM Color Rubber Dredging Hose Leak Proof Heavy Duty For Water Discharge

Technical Specifications
NameNominal BoresLengthWorking PressureSafety FactorFlange Options
Discharge Hose PipeFrom 150mm (6") to 1200mm (47")Up to 11.8 Metres (38ft)Up to 20 bar4:1Fixed, Swivel, Double-Flange and Built-in-Nipple Designs
Detailed Specifications Table
ModelI.D. (inch)I.D. (mm)W.P. (bar)B.P. (bar)Min Bending RadiusWear Layer Thickness (mm)Length (m)
HM-DHP15061505-1015-308D10-2011.8
HM-DHP20082005-1015-308D10-2011.8
HM-DHP250102505-1015-308D10-2011.8
HM-DHP3001230010-2030-6012D12-2511.8
HM-DHP3501435010-2030-6012D12-2511.8
HM-DHP4001640010-2030-6012D12-2511.8
HM-DHP4501845010-2030-6012D12-2511.8
HM-DHP5002050010-2030-6012D12-2511.8
HM-DHP6002460015-2045-6015D20-3011.8
HM-DHP6502665015-2045-6015D20-3011.8
HM-DHP7002870020-2560-7515D30-5011.8
HM-DHP7503075020-2560-7515D30-5011.8
HM-DHP8003280020-2560-7515D30-5011.8
HM-DHP8503485020-2560-7515D30-5011.8
HM-DHP9003690025-3075-9015D30-5011.8
HM-DHP100040100025-3075-9015D50-7511.8
HM-DHP110044110025-3075-9015D50-7511.8
Key Features
  • Heavy-Duty Robust Construction: Designed to handle large dredged particles with hoop-ring or spring-wire-helix construction for flexibility or full vacuum during service
  • Tailor-Made Designs: Including self-floater, suction dredge hose and flexible discharge hoses suitable for slurries containing rock, shell and coral
  • Extremely Lightweight & Flexible: Manufactured from high-quality PVC material, significantly lighter than rubber hoses for easy coiling, uncoiling, and dragging across fields or job sites
  • Reinforced Construction: High-tensile polyester yarn braid reinforcement provides sufficient strength for typical water discharge pressures (up to 150 PSI)
  • Weather & UV Resistant: PVC compound treated with UV stabilizers to resist degradation from sunlight
  • Smooth Interior for Efficient Flow: Smooth inner surface ensures efficient water flow with minimal friction loss
Applications
  • Agriculture Irrigation: Crop irrigation, drainage of fields, and water transfer for farming and gardening applications
  • Construction Site Dewatering: Pumping clean water from excavations, trenches, and foundations during the construction process
  • Municipal Landscape Use: Drainage for parks, sports fields, temporary water diversion for events, and general-purpose water movement by municipal crews
Why Choose Hongruntong Marine?
  • Cost Effective Sourcing: Factory-direct production of large volumes of high-quality PVC hose at highly competitive prices
  • Rapid Delivery & Large Stock Availability: Large stocks of common diameters (1" to 4") in ready-to-ship lengths
  • Custom Printing and Branding: Custom printing of company name and product specifications for branding and inventory identification
  • Reliable Quality for the Application: Engineered to be best-in-class for general water duty with perfect balance of performance, weight, and price
Frequently Asked Questions
Q: Is the hose drinking water safe?
A: Our standard PVC hose is not rated for potable water. For drinking water applications, we offer a separate hose made with FDA-approved materials and a different compound that doesn't impart taste or odor.
Q: What is the temperature range?
A: This PVC hose is designed for water temperatures between 0°C (32°F) and 60°C (140°F). It can become stiff in very cold weather and soften in high heat.
Q: Can it handle mild chemicals?
A: It has fair resistance to mild acids and alkalis but is not recommended for strong solvents, oils, or fuels, which will degrade the PVC material.
