Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-MH9
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
China
MOQ :
1
Price :
$70-$698
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
2689 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Reinforcement layer :
Synthetic Fabric and Wire Helix
Tube :
Grade A++ Natural Rubber
Cover :
Synthetic Rubber
Temperature Range :
-40°C~70°C
Working Pressure :
10-22 Bar
Color :
Black Or As Your Request
Application :
Designed for Use In Heavy Duty Mining and Industrial Applications
Description
Mining Hose - Extreme Abrasion & Chemical Resistance
The Hongruntong Mining Hose is specifically engineered for high-impact, high-vibration mining operations, such as mobile slurry pumping, pump trucks, and conveyor connections. Constructed with multi-layer synthetic reinforcement and high-elasticity rubber linings, the hose offers exceptional resistance to mechanical shock, fatigue, and repeated bending cycles, while maintaining pressure stability and chemical compatibility.
Case Study: Queensland Coal Mine
In 2022, a coal mine in Queensland, Australia, implemented our 12-inch Mining Hose with triple synthetic reinforcement and impact-resistant rubber lining for mobile slurry pump units. During 14 months of operation with weekly relocations, the hoses maintained structural integrity despite high-pressure surges up to 22 bar, repeated bending, and mechanical impacts. The mine reported a 35% reduction in hose replacement costs and improved operational flexibility.
Custom Abrasion Resistant Mining Pipe Corrosion Resistance Mining Piping Systems
Custom Abrasion Resistant Mining Pipe Corrosion Resistance Mining Piping Systems
Technical Specifications
Product NameMining Hose
BrandHongruntong Marine
Tube MaterialHongruntong Grade A++ Natural Rubber
ReinforcementSynthetic Fabric and Wire Helix
CoverUV, Ozone, and Abrasion-Resistant Synthetic Rubber
Working Pressure10-22 Bar
Temperature Rating-40°C to +80°C
Safety Factor4:1
Application Specifications
Application ScenarioRecommended ID (mm)Wall Thickness (mm)Working Pressure (Bar)Temperature Range (°C)
Slurry and Tailings Transport100-30015-256-10-30 to +80
Mine Dewatering Systems50-20010-204-8-10 to +60
Dust Suppression Lines25-1005-154-6-10 to +50
Chemical Transfer in Processing50-15010-226-10-20 to +90
Product Models
ModelInner Diameter (ID)Outer Diameter (OD)Working Pressure (MPa)Burst Pressure (MPa)Bend Radius (mm)Standard Length (m)Liner Thickness (mm)
HM-MH176 mm (3")120-140 mm1.0-1.63.0-4.8600-80010 / 208-12
HM-MH2100 mm (4")150-170 mm1.0-2.03.0-5.0700-90010 / 208-15
HM-MH3125 mm (5")185-210 mm1.0-2.03.0-6.0900-110010 / 2010-18
HM-MH4150 mm (6")230-260 mm1.0-2.53.0-7.51000-130010 / 2012-20
HM-MH5200 mm (8")300-340 mm1.2-2.54.0-8.01200-160010 / 2012-25
HM-MH6250 mm (10")360-420 mm1.2-3.04.0-9.01500-200010-11.815-28
HM-MH7300 mm (12")420-500 mm1.2-3.04.0-9.01800-240010-11.818-30
HM-MH8350 mm (14")500-580 mm1.0-2.53.0-7.52200-300010-11.820-32
HM-MH9400 mm (16")560-650 mm1.0-2.53.0-7.52500-330010-11.822-35
HM-MH10500 mm (20")680-780 mm1.0-2.03.0-6.03000-420010-11.825-40
Key Features
  • Impact-Resistant Design: High-elasticity outer layer and reinforced structure absorb mechanical shocks and impacts without cracking or leaking
  • Fatigue and Flexibility Resistance: Endures thousands of bending cycles without kinking, wall delamination, or loss of pressure integrity
  • High Pressure Stability: Maintains pressure integrity up to 25 bar with even pressure distribution across reinforcement layers
  • Chemical and Abrasion Resistance: Inner lining resists acidic/alkaline slurries and abrasive particles, retaining over 90% of wall thickness after extended exposure
Applications
  • Mobile Pump Units and Slurry Transfer
  • Temporary Pipelines and Conveyors
  • High Vibration Equipment Interfaces
Why Choose Hongruntong Marine
  • Engineering for Dynamic Mining Operations: Advanced reinforcement structures and high-elasticity rubber compounds for vibration and shock resistance
  • Field Tested Reliability: Proven performance in coal, iron ore, and gold mines under dynamic conditions
  • Tailored Customization: Custom diameters, reinforcement layers, rubber compounds, and lengths for specific application requirements
  • Comprehensive Support: Full lifecycle support including installation guidance, maintenance schedules, and emergency replacement
Frequently Asked Questions
Can this hose handle repeated bending without failure?
Yes, the hose is designed for thousands of bending cycles while maintaining structural integrity and pressure stability.
Is it suitable for use with mobile slurry pumps?
Absolutely, it is optimized for mobile pump units, with high impact and vibration resistance.
What pressure can the hose withstand during dynamic operation?
It safely handles pressures up to 25 bar, even under repeated movement and bending.
How resistant is it to abrasion from slurry and tailings?
The inner lining resists highly abrasive slurries, maintaining over 90% of wall thickness after prolonged exposure.
Can Hongruntong provide emergency support for mobile operations?
Yes, we provide rapid-response replacement, technical consulting, and maintenance support for mobile and temporary setups.
