Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-MH08
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
Beijing, China
MOQ :
1
Price :
$66-$892
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
4560 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Brand :
Hongruntong Marine
Tube :
Grade A++ Natural Rubber
Reinforcement layer :
Synthetic Fabric and Wire Helix
Cover :
Synthetic Rubber
Temperature Range :
-40°C~70°C
Working Pressure :
10-22 Bar
Color :
Black Or As Your Request
Standard :
Meets Or Exceeds Sae 100r4
Application :
Designed for Use In Heavy Duty Mining and Industrial Applications
Description
6" Mining Hose High Abrasion NR Liner Multi Layer Reinforced Structure
Product Overview

Mining hoses are heavy-duty flexible hoses specially designed for harsh mining environments, widely used for conveying water, air, slurry, oil, and other media in underground and surface mining operations. Made with wear-resistant rubber and reinforced with high-strength steel wire or fabric, they feature excellent pressure resistance, bending performance, and durability to withstand long-term friction, impact, and mechanical stress.


These hoses are typically constructed with an anti-wear inner tube, reinforced middle layer, and weather-resistant outer cover, many also equipped with anti-static and flame-retardant properties to meet strict mine safety standards. They play an essential role in mining machinery, dust control, dewatering, hydraulic systems, and mineral slurry transportation, ensuring stable and safe operation in complex working conditions.

Technical Specifications
Product Name Mining Rubber Hose
Brand Hongruntong Marine
Tube Material Hongruntong Grade A++ Natural Rubber
Reinforcement Synthetic Fabric and Wire Helix
Cover UV, Ozone, and Abrasion-Resistant Synthetic Rubber
End Connections Carbon Steel (Painted, Galvanised, Custom)
Stainless Steel (SS304, SS316)
Exotic Alloy
Working Pressure 10-22 Bar
Temperature Rating -40°C to +80°C
Safety Factor 4:1
Application Specifications
Application Scenario Recommended ID (mm) Wall Thickness (mm) Working Pressure (Bar) Temperature Range (°C)
Slurry and Tailings Transport 100-300 15-25 6-10 -30 to +80
Mine Dewatering Systems 50-200 10-20 4-8 -10 to +60
Dust Suppression Lines 25-100 5-15 4-6 -10 to +50
Chemical Transfer in Processing 50-150 10-22 6-10 -20 to +90
6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure
6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure
6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure
Key Features
  • Abrasion Resistant Inner Tube: The hose features a high-grade synthetic rubber or polyurethane liner specifically designed to withstand the constant friction caused by abrasive materials like slurry, sand, and rocks.
  • High-Tensile Reinforcement Layers: Reinforced with multi-ply synthetic fabric or steel wire to provide excellent pressure tolerance and structural integrity in demanding applications.
  • UV and Weather Resistance: The outer cover is engineered with UV-stabilized compounds to prevent degradation from prolonged exposure to sunlight, ozone, and harsh outdoor environments.
  • Flexible Structure for Easy Routing: Designed with flexibility in mind, allowing the hose to be laid easily around equipment, over terrain, and into pits without kinking or cracking.
Applications
  • Temporary Dewatering
  • Tunnel Dust Control
  • Washdown Stations
  • Portable Water Lines
Product Advantages
  • High Abrasion Resistance: Mining hoses are built with wear-resistant inner linings, allowing them to handle abrasive materials like slurry, sand, gravel, and ore without premature wear.
  • Exceptional Flexibility: Designed to remain flexible in harsh and dynamic environments, these hoses can easily navigate complex routing in both open-pit and underground operations.
  • Wide Pressure Range Compatibility: Mining hoses are available in both low- and high-pressure variants, making them suitable for various tasks from dewatering to high-pressure slurry pumping.
  • Chemical Resistance: Specialized liners (e.g., NR, SBR, EPDM, or composite materials) allow safe conveyance of acids, alkalis, solvents, and other aggressive chemicals.
Frequently Asked Questions
Q: Can it handle hot water?
A: Yes, up to 60°C.
Q: Is this hose suitable for acidic media?
A: Not recommended for strong acids.
Q: What lengths are available?
A: Up to 100 meters per roll.
Q: Does it come in different colors?
A: Yes, commonly in blue, yellow, and green.
6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure
6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure

6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure

6'' Mining Industry Hose High Abrasion NR Liner Multi Layer Reinforced Structure
