Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-MH01
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
Beijing, China
MOQ :
1
Price :
$35-$670
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
868 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Brand :
Hongruntong Marine
Name :
Mining Hose
Tube :
Grade A++ Natural Rubber
Reinforcement layer :
Synthetic Fabric and Wire Helix
Cover :
Synthetic Rubber
Temperature Range :
-40°C~70°C
Working Pressure :
10-22 Bar
Color :
Black Or As Your Request
Standard :
Meets Or Exceeds Sae 100r4
Application :
Designed for Use In Heavy Duty Mining and Industrial Applications
Description
10'' Tailings Hose Epdm Outer Cover Excellent Uv Weather And Ozone Resistance
Introduction

The Composite Mining Hose is a multi-layered, high-performance solution for handling aggressive chemicals, fuels, and abrasive slurries. Its layered construction combines plastic films, woven fabrics, and internal helixes to ensure flexibility, strength, and chemical resistance. This hose is particularly suitable for operations involving acids, solvents, or oil-based materials. It is lightweight, yet rugged enough to handle rough terrain and high flow applications in open-pit or processing facilities.

Specifications
Product Name Mining Rubber Hose
Brand Hongruntong Marine
Tube Material Hongruntong Grade A++ Natural Rubber
Reinforcement Synthetic Fabric and Wire Helix
Cover Uv, Ozone, and Abrasion-Resistant Synthetic Rubber
End Connections Carbon Steel (Painted, Galvanised, Custom)
Stainless Steel (Ss304, Ss316)
Exotic Alloy
Working Pressure 10-22 Bar
Temperature Rating -40°C to +80°C
Safety Factor 4:1
Application Scenario Recommended ID (mm) Wall Thickness (mm) Working Pressure (Bar) Temperature Range (°C)
Slurry and Tailings Transport 100–300 15–25 6–10 -30 to +80
Mine Dewatering Systems 50–200 10–20 4–8 -10 to +60
Dust Suppression Lines 25–100 5–15 4–6 -10 to +50
Chemical Transfer in Processing 50–150 10–22 6–10 -20 to +90

10'' Multi Layered Mining Hose Ozone Resistance Material Handling Hose10'' Multi Layered Mining Hose Ozone Resistance Material Handling Hose

Features
Color Coded for Media Type or Safety

Available in different colors for quick identification of fluid type or to comply with safety regulations in complex operations.

Vacuum Capable Design

Some mining hoses are reinforced to handle suction applications, such as dewatering, slurry intake, or dust extraction.

Easy to Cut and Join On Site

Modular hose systems can be easily cut and reconnected using standard tools and couplings, minimizing downtime during field repairs.

Low Maintenance and Long Lifespan

Engineered to reduce wear and failure, minimizing the frequency of inspections, replacements, and system downtime.

Application
  • Slurry and Tailings Transport
  • Mine Dewatering Systems
  • Dust Suppression Lines
  • Chemical Transfer in Mineral Processing
Advantages
Quick Coupling and Disconnection Options

Mining hoses can be fitted with a wide variety of connectors—flanged, camlock, or custom quick-release fittings—enabling fast setup and system reconfiguration, which is essential in dynamic mining environments.

Minimal Pressure Drop Over Distance

Due to smooth bore design and optimized internal geometry, mining hoses maintain steady pressure even over long lengths, improving pumping efficiency and reducing energy consumption.

Resistance to Hydrocarbon and Oil Exposure

Many mining hoses feature oil-resistant outer layers (e.g., NBR blends), making them suitable for environments where contact with diesel, lubricants, or hydraulic fluid is common.

Modular and Replaceable Sections

In the event of localized wear or damage, individual hose sections can be easily replaced without dismantling an entire system—saving both time and cost.

FAQ
1. Q: Can this hose handle sulfuric acid?

A: Yes, with the appropriate liner.

2. Q: Is it suitable for above-ground use?

A: Yes, it’s weather and UV resistant.

3. Q: What is the burst pressure rating?

A: Typically 4x the working pressure.

4. Q: How is it connected to fittings?

A: Flanged or threaded ends are available.
