Specifications
Brand Name :
Hongruntong Marine
Model Number :
HM-RDH364
Certification :
ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
Place of Origin :
China
MOQ :
1
Price :
$7-$240
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1250 Pcs Per Month
Delivery Time :
5-7 Work Days
Packaging Details :
Wooden Pallets, Wooden Box
Product Name :
Rotary Drilling Hose
Cover :
High Quality Synthetic Rubber
Working Pressure :
35 Mpa - 75 Mpa
Reinforcement :
High Tensile Steel Wire
Material :
Natural Rubber
Connnection type :
Hammer Union / Flange
Color :
Black
Machine Type :
Drilling Equipment
Application :
Petroleum Base Hydraulic Fluids
Warranty :
3 Years
Description
Ruber Rotary Drilling Hose With Fitting And Clamp For Shale Gas Exploration
Product Overview

The Rotary Drilling Hose is a high-pressure hose used in oil and gas exploration to deliver drilling fluids from the mud pump to the drill string. Designed for extreme working conditions, it features a reinforced structure with multiple layers of high-tensile steel wire and synthetic rubber for excellent flexibility, durability, and resistance to abrasion.

The hose is resistant to oil, heat, and weather, ensuring long service life in harsh environments. It complies with API 7K standards and is suitable for both onshore and offshore drilling operations. With its superior performance and reliability, the Rotary Drilling Hose enhances efficiency and safety in drilling applications.

High Pressure Ruber API Rotary Drill Pipe For Shale Gas Exploration High Pressure Ruber API Rotary Drill Pipe For Shale Gas Exploration
Technical Specifications
Tube Modified nitrile, black, specifically engineered for the effective handling of abrasive, corrosive substances, and oil drilling mud.
Reinforcement Composite construction featuring multiple layers of textile fabric and steel cable, with a layer of rubber positioned between the cable layers for enhanced performance.
Cover Black modified nitrile with a specially engineered ultra-abrasion cover, designed to provide exceptional resistance to abrasion, corrosion, cutting, gouging, oil, and weather conditions.
Coupling Swaged couplings, full range of couplings are available, such as hammer union, flanges, hubs, male thread etc.
Certification API 7K-0376/ISO14693
Temperature -40°C to +82°C (-104°F to +180°F)
Options Accessories such as safety clamps and hose lift eyes are available upon request
Test Each hose is tested at 22500psi for 15 minutes. Pressure test graph, test certificate and letter of conformance are issued for each hose.
Key Features
Onshore Offshore Compatibility

Suitable for both land based and offshore drilling rigs.

Extended Service Life

Engineered for long-term use, reducing replacement frequency and maintenance costs.

Shock Vibration Absorption

Effectively absorbs shocks and vibrations, ensuring stable drilling operations.

Customizable Specifications

Available in various sizes, lengths, and pressure ratings to meet specific drilling needs.

Engineered for the Toughest Applications
Onshore Oil Drilling Rigs

Used to transfer high-pressure drilling mud from the mud pump to the drill string in land-based drilling operations.

Offshore Oil Drilling Platforms

Essential for offshore drilling rigs, ensuring the safe and efficient circulation of drilling fluids under harsh marine conditions.

Deepwater Drilling Operations

Designed to withstand extreme water depths and pressures, maintaining reliable drilling fluid transfer.

Shale Gas Exploration

Supports hydraulic fracturing (fracking) operations by delivering high-pressure drilling fluids in unconventional oil and gas extraction.

What Sets Us Apart
Over 30 Years of Manufacturing Expertise

Decades of experience ensure superior product quality and technical excellence.

High Quality Raw Materials

Sourced from trusted suppliers to guarantee durability, flexibility, and resistance to harsh environments.

Advanced Production Technology

State-of-the-art machinery and automated processes ensure precision and consistency.

Strict Quality Control System

Comprehensive inspection and testing procedures ensure every hose meets the highest industry standards.

Product Specifications Table
Model I.D. (inch) I.D. (mm) O.D. (mm) W.P. mpa(psi) T.P. mpa(psi) Weight (kg/m) B.R. (mm)
HMRDH-Grade A 1 1/2 38 51 11(1500) 22(3000) 2.19 560
HMRDH-Grade A 2 51 65 11(1500) 22(3000) 3.03 900
HMRDH-Grade A 2 1/2 64 78 11(1500) 22(3000) 3.95 1200
HMRDH-Grade B 1 1/2 38 52 14(2000) 28(4000) 2.39 560
HMRDH-Grade B 2 51 66 14(2000) 28(4000) 3.25 900
HMRDH-Grade B 2 1/2 64 79 14(2000) 28(4000) 4.37 1200
HMRDH-Grade B 3 76 98 14(2000) 28(4000) 7.76 1200
HMRDH-Grade B 3 1/2 89 113 14(2000) 28(4000) 9.95 1300
HMRDH-Grade B 4 102 127 14(2000) 28(4000) 12.43 1400
HMRDH-Grade B 5 127 153 14(2000) 28(4000) 15.25 1500
HMRDH-Grade B 6 152 178 14(2000) 28(4000) 18.71 1600
HMRDH-Grade C 1 1/2 38 55 28(4000) 56(8000) 3.65 560
HMRDH-Grade C 2 51 69 28(4000) 56(8000) 5.15 900
HMRDH-Grade C 2 1/2 64 88 28(4000) 56(8000) 7.86 1200
HMRDH-Grade C 3 76 105 28(4000) 56(8000) 13.12 1200
HMRDH-Grade C 3 1/2 89 121 28(4000) 56(8000) 16.79 1300
HMRDH-Grade C 4 102 137 28(4000) 56(8000) 21.70 1400
HMRDH-Grade C 5 127 164 28(4000) 56(8000) 28.46 1500
HMRDH-Grade C 6 152 197 28(4000) 56(8000) 44.64 1600
HMRDH-Grade D 2 51 73 35(5000) 70(10000) 6.46 900
HMRDH-Grade D 2 1/2 64 91 35(5000) 70(10000) 10.75 1200
HMRDH-Grade D 3 76 107 35(5000) 70(10000) 14.35 1200
HMRDH-Grade D 3 1/2 89 123 35(5000) 70(10000) 18.77 1300
HMRDH-Grade D 4 102 139 35(5000) 70(10000) 23.16 1400
HMRDH-Grade D 5 127 171 35(5000) 70(10000) 38.00 1500
HMRDH-Grade D 6 152 200 35(5000) 70(10000) 48.43 1600
HMRDH-Grade E 2 51 80 52(7500) 104(15000) 10.37 1000
HMRDH-Grade E 2 1/2 64 101 52(7500) 104(15000) 17.88 1200
HMRDH-Grade E 3 76 120 52(7500) 104(15000) 24.45 1200
HMRDH-Grade E 3 1/2 89 135 52(7500) 104(15000) 29.33 1300
HMRDH-Grade E 4 102 148 52(7500) 104(15000) 34.24 1400
HMRDH-Grade E 5 127 189 52(7500) 104(15000) 55.39 1500
HMRDH-Grade F 2 51 82 70(10000) 105(15000) 11.81 1000
HMRDH-Grade F 2 1/2 64 104 70(10000) 105(15000) 20.46 1300
HMRDH-Grade F 3 76 129 70(10000) 105(15000) 32.74 1300
HMRDH-Grade F 3 1/2 89 144 70(10000) 105(15000) 39.43 1400
HMRDH-Grade F 4 102 158 70(10000) 105(15000) 45.73 1500
HMRDH-Grade G 2 51 92 105(15000) 157(22500) 17.37 1000
High Pressure Ruber API Rotary Drill Pipe For Shale Gas Exploration

High Pressure Ruber API Rotary Drill Pipe For Shale Gas Exploration

High Pressure Ruber API Rotary Drill Pipe For Shale Gas Exploration

Frequently Asked Questions
How flexible is a Rotary Drilling Hose?

Designed with high flexibility to accommodate movement on drilling rigs.

Can Rotary Drilling Hoses be used in offshore applications?

Yes, they are built to withstand offshore and subsea drilling conditions.

Are Rotary Drilling Hoses resistant to high temperatures?

Yes, they can operate in temperatures ranging from -40°C to +100°C (-40°F to 212°F).

What makes a high performance Rotary Drilling Hose?

A combination of durable rubber, strong reinforcement, and precise manufacturing.
