55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
Specifications
Brand Name :
YOULESHI
Model Number :
ULS-55PJ02
Place of Origin :
Guangdong, China
Supply Ability :
2000 pieces per month for each product
MOQ :
1pcs
Packaging Details :
Paper box/wooden box/flying box
Certification :
CCC,RoHS,FCC,CE,UN38.3
Delivery Time :
5 working days
Application :
Indoor
Type :
LCD
Color :
FULL COLOR
Supplier Type :
ODM, OEM
Media Available :
datasheet, Photo
use :
advertising publish, retail store, shopping mall, display of dishes, exhibition hall, subway, Restaurant & Hotel Supplies, education
Function :
SDK
Specification :
Video Wall
Touch Screen Type :
Infrared
Brightness :
500nit
Display Ratio :
16:9
Response Time :
8ms
Contrast Ratio :
4000:1
Lifespan (hours) :
80000
IP Rating :
IP45
Installation Type :
hanging
Resolution :
1920*1080
View Angle（H/V） :
89°/89°/89°/89°(min)(CR≥10)
Warranty :
1-3Year
After Sales :
video
Size :
10.1 inch-110 inch
resolution :
1920*1080/3840*2160
OS :
Android/Windows
touch screen :
optional
4G :
optional
warranty :
1-3 year
Life Time :
60000 hours
Connectivity :
WiFi, Bluetooth
Panel :
100% A+ Grade Panel
Picture Format :
mp3, wma, ogg, aac, wav
Color Option :
White/Black or optional
Certificates :
CE FCC ROHS
Usb :
Yes
Max Resolution :
1920*1080/3840*2160
Screen Size :
10.1-110 inches
Operation Humidity Range :
10% to 80%
Osd Language :
English,Chinese
Contrast :
≥ 1000: 1
Input :
AC 110V~240V,50/60Hz, 110W
Touch :
optional
Description
55" 3.5mm Border Display Screen LCD Video Splicing Wall
Premium Indoor Ultra-Narrow Seam High-Definition Advertising Display
55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM 55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM 55 Inch 1920*1080 LCD Video Wall Panels With 89° Viewing Angle ODM OEM
Key Features
  • Industrial-grade design with 80,000 hours continuous operation
  • High brightness (500cd/m²), resolution (1920×1080), contrast (4000:1), and wide viewing angle
  • Ultra-narrow 3.5mm double-sided stitching for seamless video walls
  • Direct downward LED backlight system for uniform illumination
  • Built-in splicing controller for multi-screen image display
  • 3D digital image processing core for enhanced detail monitoring
  • Image signal enhancement for stable, accurate control
  • Advanced image restoration technology improves system reliability
  • Supports multiple signal inputs including HDMI, DVI, and USB
  • Flexible customizable splicing configurations
Technical Specifications
Display Parameters
Screen Size 55" DID LCD Panel
Active Display Area 1209.6(H) × 680.4(V) mm
Aspect Ratio 16:9
Bezel Width 0.88mm
Backlight WLED with LED driver
Native Resolution 1920 × 1080 pixels
Brightness 500cd/m²
Contrast Ratio 4000:1 (Typical)
Viewing Angle 89°/89°/89°/89° (CR≥10)
Response Time 8ms (Gray to Gray)
Connectivity
Ports 1× HDMI IN, 1× DVI IN, 1× USB, 1× RS232 IN, 2× RS232 OUT
Power Requirements
Working Voltage AC110V~220V 50/60Hz
Maximum Power 250W
Standby Power 0.5W
Environmental Specifications
Operating Temperature 0°C ~ 50°C
Storage Temperature -20°C ~ 60°C
Lifespan 80,000 hours
Humidity 10% ~ 80% RH
Physical Dimensions
Chassis Material Metal
Chassis Color Black
Product Size (without brackets) 1022 × 80 × 576.6 mm
Product Size (with brackets) 1214.1 × 125 × 684.6 mm
Packing Dimensions 1300 × 330 × 785 mm (2 units per carton)
Net Weight 21kg
Gross Weight 46kg (2 units)
Included Accessories

Power cable, LAN cable, Hook, Bolts, Remote control, Remote receiver, Converter

Installation Options

Wall mount | Floor stand | Arm bracket | Cabinet
