Specifications
Brand Name :
HuaXin
Model Number :
HX072-0616TBBIG41
Certification :
ISO14001/ ISO9001/IATF16949
Place of Origin :
China
MOQ :
1000
Price :
$3~$5
Payment Terms :
T/T
Supply Ability :
500K pcs per month
Delivery Time :
4~6weeks
Packaging Details :
blister+foam box+bubble bag+inside carton+master carton
Display Technology :
spi tft display
size :
2.51 inch TFT display
resolution :
60*160
Brightness :
350c/d
Interface :
4 Line SPI
Driving IC :
GC9D01
Description
HX072-0616TBBIG41 is a 60RGBX160 dot-matrix TFT LCD module. This module is composed of a TFT LCD Panel, driver ICs, FPC and a Backlight unit.
Key Specifications:
Part No: HX072-0616TBBIG41
Size 0.72 inch TFT display
Resolution 60*160
Brightness(cd/m2) 350 c/d
Active Area 6.41(H) x 17.09(V) mm
Outline dimension 8.52X21.695X1.47mm
Interface 4 Line SPI
View Angle ALL
Operating temperature -20~70
driving IC ST7701SN-G5-1

Technical Drawing
0.72 inch TFT Color Display with RTP 60*160 Resolution and MIPI Interface 350 c/d brightness
TFT Product Knowledge
TFT Substrate Input and CF Substrate Input Flow Chart
0.72 inch TFT Color Display with RTP 60*160 Resolution and MIPI Interface 350 c/d brightness
TFT Structure
0.72 inch TFT Color Display with RTP 60*160 Resolution and MIPI Interface 350 c/d brightness
Our advantage
  • Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
  • Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)

  • Certifications: ISO14001, ISO9001/IATF16949, SGS

  • Cost-effective production base located in inland city

    •Advanced equipment ensuring stable quality

    • Highly automated processes for efficiency and consistency

    • Experienced engineering team with 20+ years in LCD field

    •Custom product design capabilities

Product Applications
  • Car navigation & printer
  • Video call & advertising
  • Automotive & medical devices
  • Fitness equipment & handheld devices
  • Industrial control and home appliance
