2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
2.35 HD TFT Display 320×480 (3:2), High-Definition Screen for Industrial Controllers/Handheld Gadgets
Specifications
Brand Name :
HuaXin
Model Number :
ESHX235QV007A
Certification :
ISO14001/ ISO9001/IATF16949
Place of Origin :
China
MOQ :
1~1000
Price :
$2.5~$5.1
Payment Terms :
T/T
Supply Ability :
500K pcs per month
Delivery Time :
4~6weeks
Packaging Details :
blister+foam box+bubble bag+inside carton+master carton
Display Technology :
bar type tft display
Name :
bar type tft
Display size :
2.35 inch tft
Resolution :
320*X480(V)
interface :
MIPI
View angle :
all
Description

2.35" TFT LCD Screen - 320×480 Resolution, 3:2 Aspect Ratio, HD High Clarity for Small-Sized Devices

Key Specifications
Item Specification
Model Number HX286001B0
Size 2.35inch
LCD Type Normally Black
Resolution 320×480 pixels
Active Area 33.12(H) X49.68(V)
Driver IC ST7701S
Operating Temperature -20°C to +70°C
Product Images

2.35
2.35
2.35
2.35

Technical Drawings

2.35
TFT Display Characteristics
  • High resolution (480×640) with excellent image quality and color accuracy
  • Fast response time for smooth motion display
  • Wide viewing angles with minimal color shift
  • Energy efficient design with low power consumption
  • LED backlighting for uniform illumination
  • Robust construction for industrial applications
Product Applications
  • Automotive displays and navigation systems
  • Medical devices and diagnostic equipment
  • Industrial control systems and HMI
  • Handheld devices and portable instruments
  • Digital signage and advertising displays
Manufacturer Information
Company Advantages
  • Cost-effective production with mainland China factory
  • Advanced equipment ensuring consistent quality
  • Fully automated production processes
  • 20+ years of engineering expertise
  • Custom design capabilities for specialized applications
Certifications
  • ISO14001 Environmental Management
  • ISO9001/IATF16949 Quality Management
  • SGS certified LCD modules
Company Profile

Huaxin Technology (Enshi) Co., LTD
Location: Hubei, Enshi | Founded: 2009
Specialization: Research, development, production and sales of LCD, LCM, TFT, backlight, and OLED products

Product Range
  • LCD: VA, TN, HTN, STN, FSTN, CSTN series
  • LCM: COB, TBA, COG, TP, LED backlight series
Production Capacity
Product 2021 2022 2023 2024 2025 Unit
LCD Production 4.5 9 9 9 9 Thousands/Day
LCM Production 70 150 300 450 450 Thousand pieces/Day
Backlight Production 100 200 300 500 500 Thousand pieces/Day
OLED Production 10 20 30 40 50 Thousand pieces/Day
