5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
Specifications
Brand Name :
HuaXin
Model Number :
HX031B001
Certification :
ISO14001/ ISO9001/IATF16949
Place of Origin :
China
MOQ :
1000
Price :
$6~$100
Payment Terms :
T/T
Supply Ability :
500K pcs per month
Delivery Time :
4~6weeks
Packaging Details :
blister+foam box+bubble bag+inside carton+master carton
Display Technology :
spi tft display
name :
lcd tft spi
size :
5.2 inch
resolution :
416*1280
Brightness :
400c/d
Interface :
MIPI
Description
5.2 Inch LCD Bar Screen TFT Color LCD Display
High-resolution 416x1280 dot display with MIPI interface and JD9161Zdriving IC, featuring all-view angle capability.
Key Specifications:
Part No: HX052BFW8931ANT
Size TFT LCD 5.2 inch
Resolution 416X1280
Brightness(cd/m2) 400c/d
Active Area 40.75*125.38mm
Outline dimension 43.55*131.28*2.08mm
Interface MIPI
View Angle ALL
Operating temperature -20~70
driving IC JD9161Z

Technical Drawing
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
TFT Product Knowledge
TFT Substrate Input and CF Substrate Input Flow Chart
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
TFT Structure
5.2 Inch Lcd Bar Screen TFT Color LCD Display 416X1280 Dots LVDS Interface Driving IC JD9161Z
Our advantage
  • Founded in 2009 in Hubei Enshi, specializing in LCD, LCM, TFT, backlight, and OLED research, development, and production.Product range includes VA, TN, HTN, STN, FSTN, CSTN LCDs and COB, TBA, COG, TP, LED backlight LCMs.
  • Registered capital: 20 million | Staff: 500+ (10% R&D, 15% QC)

  • Certifications: ISO14001, ISO9001/IATF16949, SGS

  • Cost-effective production base located in inland city

    •Advanced equipment ensuring stable quality

    • Highly automated processes for efficiency and consistency

    • Experienced engineering team with 20+ years in LCD field

    •Custom product design capabilities

Product Applications
  • Car navigation & printer
  • Video call & advertising
  • Automotive & medical devices
  • Fitness equipment & handheld devices
  • Industrial control and home appliance
