Specifications
Brand Name :
maxell
Model Number :
CR2032/CR2025/CR2016/CR1632/CR1620/CR1616/CR1220
Certification :
ROHS
Place of Origin :
JP
MOQ :
1
Price :
0.96
Payment Terms :
Western Union,T/T
Supply Ability :
100000
Delivery Time :
5-8day
Packaging Details :
T/R
Nominal voltage (V) :
3
Nominal capacity (mAh)*1 :
25~250mAh
Nominal discharge current (mA) :
0.1~0.2
Operating temperature range (deg. C)*2 :
-20 to +85
Description

Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016


The coin type lithium manganese dioxide battery (CR battery) is a small, lightweight battery with an operating voltage of 3 V and the ability to operate over a wide temperature range. It has a wide range of applications for powering devices such as various IoT sensors, medical equipment, data loggers and wearable devices.


Features

Stable operating voltage under long-term low load discharge for Memory and RTC backup

Stable discharge characteristics through low internal resistance and high operating voltage

Employs highly conductive electrolyte, lowering internal resistance and providing stable operating voltage. This allows stable power to be obtained, with little change in operating voltage at high and low temperatures.

Superior leakage resistance and excellent storage characteristics

Employs a leak-resistant organic electrolyte, giving it better leakage resistance than battery types using alkaline electrolytes.

Furthermore, Maxell’s proprietary sealing structure achieves approximately 1% self-discharge rate.

Superior high rate discarge characteristics

Stable discharge until the end of the discharge process.

The CR2032S, with its new design specifically tailored for communication purposes, maintains stable performance even as discharge progresses. In a test mode designed for compact communication devices, it achieved an 11% improvement in operating time.*

* Maintains a voltage of 2.0 V or higher under discharge conditions of a 10 mA, 350 msec pulse current at 20 deg. C.

UL Recognized Components

The coin type lithium manganese dioxide battery is a UL recognized component and user replaceable.

Recognized models: CR2032S, CR2032H, CR2032, CR2025, CR2016, CR1632, CR1620, CR1616, CR1220, CR1216

Certification number: MH12568

Applications

  • IoT sensors
  • Communication tags, beacons
  • Wearable devices
  • Medical thermometers, activity trackers
  • CGM (Continuous Glucose Monitoring)
  • DDS (Drug Delivery Systems)
  • Keyless entry systems
  • FA instruments (Measuring instruments, onboard microcomputers, sensors)
  • Model CR2032 CR2032H CR2032S CR1216 CR1220 CR1616 CR1620 CR1632 CR2016 CR2025
    Nominal voltage (V) 3 3 3 3 3 3 3 3 3 3
    Nominal capacity (mAh)*1 220 240 250 25 36 55 80 140 90 170
    Nominal discharge current (mA) 0.2 0.2 0.2 0.1 0.1 0.1 0.1 0.1 0.1 0.2
    Operating temperature range (deg. C)*2 -20 to +85
    Dimensions*3 Diameter (mm) 20.0 20.0 20.0 12.5 12.5 16.0 16.0 16.0 20.0 20.0
    Height (mm) 3.2 3.2 3.2 1.6 2.0 1.6 2.0 3.2 1.6 2.5
    Weight (g)*3 3.0 3.0 2.8 0.6 0.8 1.1 1.3 1.9 1.7 2.5

  • Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

    Coin Type Lithium Manganese Dioxide Batteries CR Series CR2032 CR2025 CR2016

  • Packaging and transportation instructions

    - According to the standard export packaging.

    Customers can choose from cartons, wooden cases and wooden pallets according to their own requirements.
