Clock Buffer Driver Distributor Chip 9DBL0641BKILFT

Description
2 to 8-Output 3.3V PCIe
Zero-Delay/Fanout Buffers
Features
The 9DBL02x2/9DBL04x2/ 9DBL06x1/9DBL08x1 buffers are
low-power, high-performance members of Renesas' full featured
PCIe family. The buffers support PCIe Gen1 through Gen5.
9DBL02x2/9DBL04x2/
9DBL06x1/9DBL08x1
Datasheet
▪ 2 to 8 Low-Power HCSL (LP-HCSL) outputs eliminate 4
resistors per output pair
▪ 9DBLxx4x devices provide integrated 100Ω terminations
▪ 9DBLxx5x devices provide integrated 85Ω terminations
PCIe Clocking Architectures
▪ Common Clocked (CC)
▪ Independent Reference (IR) with and without spread spectrum
(SRIS, SRNS)
Typical Applications
▪ PCIe Riser Cards
▪ nVME Storage
▪ Networking
▪ Accelerators
▪ Industrial Control/Embedded
Key Specifications
▪ Additive PCIe Gen5 CC jitter < 60fs RMS (fan-out mode)
▪ PCIe Gen5 CC jitter < 150fs RMS (High-BW ZDB Mode)
