AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
Specifications
MOQ :
1
Price :
consult with
Payment Terms :
T/T,Western Union
Supply Ability :
100000
Delivery Time :
5-8days
Packaging Details :
T/R
Brand Name :
MICROCHIP
Model Number :
AT24C08C-SSHM-T
Certification :
rohs
Place of Origin :
CN
Moisture Sensitive: :
Yes
Operating Supply Voltage: :
1.8 V to 5.5 V
Product Type: :
EEPROM
Subcategory: :
Memory & Data Storage
Supply Current - Max: :
3 mA
Unit Weight: :
0.019048 oz
Description
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
AT24C08C-SSHM-T EEPROM 8K (1024x8) 2-WIRE NiPdAu 1.7V
Key Features
  • Low-Voltage Operation: VCC = 1.7V to 5.5V
  • Memory Organization: Internally organized as 1,024 x 8 (8K)
  • Temperature Range: Industrial grade -40°C to +85°C
  • I2C-Compatible Serial Interface:
    • 100 kHz Standard mode, 1.7V to 5.5V
    • 400 kHz Fast mode, 1.7V to 5.5V
    • 1 MHz Fast Mode Plus (FM+), 2.5V to 5.5V
  • Schmitt triggers and filtered inputs for noise suppression
  • Bidirectional data transfer protocol
  • Write-protect pin for full array hardware data protection
  • Ultra low power consumption: 3 mA active current maximum, 6 μA standby current maximum
  • 16-byte page write mode with partial page writes allowed
  • Random and sequential read modes
  • Self-timed write cycle within 5 ms maximum
  • ESD protection > 4,000V
  • High Reliability:
    • Endurance: 1,000,000 write cycles
    • Data retention: 100 years
  • Green package options (lead-free/halide-free/RoHS compliant)
  • Die sale options: wafer form and tape and reel available
Reliability Specifications
Operation Test Condition Min. Max. Units
Write Endurance TA = 25°C, VCC = 3.3V, Page Write mode 1,000,000 -- Write Cycles
Data Retention TA = 55°C 100 -- Years
