Specifications
Brand Name :
LANBAO
Model Number :
PDB-CM8TGI
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
USD$200
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500pc
Delivery Time :
in stock
Packaging Details :
carton
Model NO :
PDB-CM8
Customized :
Non-Customized
Center Distance :
8m
Average optical power :
20mW
Description


LANBAO PDB series RS-485/Analog 8m Laser distance Sensor

Feature description
Adoption of TOF principle, not affected by objects' color or material.
1.Extended sensing distance, suitable for a variety of applications.
2.Favorable detection accuracy and repeat accuracy.
3.Infrared laser spot, detection of small objects.


LANBAO Laser Distance Measuring Sensor PDB Series PDB-CM8TGI

Plastic Housing
RS485 PDB-CM8DGR
4..20mA PDB-CM8TGI
Technical specifications
Detection type Distance measurement
Detection range 0.1...8m Detection object is 90% white card
Supply voltage RS-485:10...30VD;4...20mA:12...30VDC
Consumption current ≤70mA
Load current 200mA
Voltage drop <2.5V
Light source Infrared laser(850nm); Laser level: Class 3
Working principle TOF
Average optical power 20mW
Impulse duration 200us
Impulse frequency 4KHZ
Testing frequency 100HZ
Light spot RS-485:90*90mm(at 5m meter); 4...20mA:90*90mm(at 5m meter)
Resolution 1mm
Linear accuracy RS-485:±1%F.S.; 4...20mA:±1%F.S.
Repeat accuracy ±1%
Response time 35ms
Dimensions 20mm*32,5mm*10.6mm
Output 1 RS-485(Support Modbus protocol); 4...20mA(Load resistance<390Ω)
Output 2 PUSH-PULL/NPN/PNP And NO/NC Settable
Dimensions 65mm*51mm*23mm
Distance setting RS-485:button/RS-485 setting; 4...20mA:button setting
Indicator Power indicator: Green LED; Action indicator: Orange LED
Hysteresis 1%
Circuit protection Short circuit protection, overload protection, reverse polarity protection,Zener protection
Built-in function Button to lock, button to unlock, action point setting,Output setting, average setting,Single point teach; Window teach mode setting,Output curve up/ down; factory date reset
Service environment Operating temperature:-10…+50ºC;
Anti-ambient light <20,000lux
Degree of protection IP67
Housing material Housing: ABS; Lens cover: PMMA
Vibration resistance 10...55Hz Double amplitude1mm,2H each in X,Y,Z directions
Impulse resistance 500m/s²(About 50G) 3 times each in X,Y,Z directions
Connection way RS-485:2m 5pins PVC cable;4...20mA:2m 4pins PVC cable
Accessory Screw(M4×35mm)×2, Nut×2, Washer×2,Mounting bracket, Operation manual
