Specifications
Brand Name :
Xianda Machinery
Model Number :
Create 600
Certification :
API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
Place of Origin :
Jinjiang, Fujian, China
Place Of Origin :
Jinjiang,Fujian,China
MOQ :
1
Price :
To Be Negotiable
Payment Terms :
L/C， T/T， D/P， Western Union ，Paypal ，Money Gram， Others
Supply Ability :
1000 Sets/Year
Delivery Time :
1 Month
Packaging Details :
Plastic Package, Suitable For Sea Transportation
Product name :
5-Axis Stone Cutting Machine
Control System :
CNC
Type :
Bridge Type Machine
Max Lifting Travel :
500mm
Power :
30KW
Safety System :
Available
Origin :
Jinjiang, Fujian, China
After-sales service provided :
Online support,Video technical support,Field maintenance and repair service,Overseas third-party support available
Description
5-Axis Stone Cutting Machine with 500mm Max Lifting Travel
Key Features
5-Axis CNC Precision Control with ±0.02mm repeat positioning accuracy
Industrial-Grade Stability with oil-immersed linear guideways and ball screw transmission
Multi-Functional Versatility for processing various stone materials and complex shapes
Space-Smart Design with compact footprint and intuitive CNC interface
Technical Specifications
Attribute Value
Product Name 5-Axis Stone Cutting Machine
Control System CNC
Type Bridge Type Machine
Max Lifting Travel 500mm
Power 30KW
Safety System Available
Origin Jinjiang, Fujian, China
After-sales Service Online support, Video technical support, Field maintenance, Overseas third-party support
5-Axis Stone Cutting Machine with DDX system
5-Axis Stone Cutting Machine with DDX system
5-Axis Stone Cutting Machine with DDX system
5-Axis Stone Cutting Machine with DDX system
5-Axis Stone Cutting Machine with DDX system
Detailed Specifications
Parameter Unit Create 450 Create 600
Blade diameter range mm 350-450 350-600
Max processing size mm 3200*2000*120 3400*2000*180
Lifting stroke mm 300 500
Worktable size mm 3200*2000 3400*2000
Table tilting degree ° 0-85° 0-85°
Head rotating degree ° 0-360° 0-360°
Air speed m/min 15 15
Repeated accuracy of positioning mm 0.1mm/1000 0.1mm/1000
Main motor kw 18.5 (Permanent magnetic system synchronous motor) 22 (Permanent magnetic system synchronous motor)
Gross power kw 26 30
Water consumption m³/h 3 3
Outline dimension mm 5600*3600*3500 5800*3650*3900
Head tilting degree ° 0-90° 0-90°
Gross weight kg 6000 7500
Support and Services
Installation guidance and setup assistance
Technical troubleshooting support
Operator training sessions
Regular maintenance services
Packing and Shipping

The machine is securely packed in a sturdy wooden crate to ensure safe transportation. We ship worldwide using trusted shipping services and provide tracking information for all orders.
