Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Specifications
Model Number :
BTC-2200/2500/2800
Delivery Time :
30 days
Product name :
Block Cutting Machine
Max blade diameter :
2200/2500/2800mm
Lifting stroke :
1320mm
Water consumption :
15m³/h
Moving front&back travel :
2200mm
Application :
Granite Marble slabs
Gross weight :
14000kg
Brand Name :
Xianda Machinery
Certification :
API, CCC, UL, SONCAP, GOST, ISO, CE, SGS;IAF
Place of Origin :
Jinjiang, Fujian, China
MOQ :
1
Price :
To Be Negotiable
Payment Terms :
L/C, T/T, D/A, D/P, ,
Supply Ability :
1000 Sets/Year
Packaging Details :
Plastic Package, Suitable for Sea Transportation.
Description
Block Cutting Machine For Granite And Marble
Product Specifications
Attribute Value
Product name Block Cutting Machine
Max blade diameter 2200/2500/2800mm
Lifting stroke 1320mm
Water consumption 15m³/h
Moving front&back travel 2200mm
Application Granite Marble slabs
Gross weight 14000kg
Product Description

This advanced block cutting machine features inverter-controlled left-right feeding with adjustable speed settings for different stone types. The hydraulic lifting system and high-precision screw nut driving mechanism ensure accurate forward-backward slicing with automatic operation. Constructed with imported materials for durability, this machine can be ground-mounted to save workspace and reduce maintenance costs.

Key Features:
  • High cutting efficiency and slicing precision
  • Excellent plate flatness after cutting
  • Exceptional operational stability
  • User-friendly controls
  • Optimized for high-value granite and marble blocks
Technical Parameters
Parameter Max blade diameter Left and right travel Moving front&back travel Lifting stroke Main motor Gross power Outline dimension Water consumption Gross weight
BTC-2200 2200mm 3800mm 2200mm 1320mm 45/55kw 57/67min/㎡ 8000*4800*3700mm 15m³/h 14000kg
BTC-2500 2500mm 3500mm 2200mm 1320mm 45/55kw 57/67min/㎡ 8000*4800*3700mm 15m³/h 14500kg
BTC-2800 2800mm 3200mm 2200mm 1320mm 55/65kw 67/77min/㎡ 8000*4800*3700mm 15m³/h 15000kg
Product Images
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
Block Cutting Machine For Granite And Marble
