TOKYO KEIKI DG4M4-32A-24DC-20-JA Miniature Solenoid Valve
TOKYO KEIKI DG4M4-32A-24DC-20-JA Miniature Solenoid Valve
Specifications
Delivery Time :
7-14 Days
Spool Type :
No. 32 / Closed-Center Transition
Model Number :
DG4M4-32A-24DC-20-JA
Mounting / Design :
Gasket Mounting / Design 20 / JA Specification
Payment Terms :
T/T
Solenoid Voltage :
24 VDC
Electrical Connection :
Standard Two-Connector Arrangement, Indicator Lamp Omitted
Price :
USD 226.80 /Unit
Packaging Details :
Brand new original packaging
Maximum Flow :
Up to 20 L/min, Depending on Pressure and Flow Path
Supply Ability :
10Units per Month
Operating Arrangement :
2 Position, Spring Offset A, Single Solenoid
Maximum Working Pressure :
21 MPa
Place of Origin :
Japan
Valve Type :
Miniature Wet-Armature Solenoid Directional Valve
MOQ :
1 unit
Brand Name :
TOKYO KEIKI
Description

TOKYO KEIKI TOKIMEC DG4M4-32A-24DC-20-JA Miniature Solenoid Valve

The TOKYO KEIKI TOKIMEC DG4M4-32A-24DC-20-JA is a compact wet-armature directional control valve featuring a two-position spring-offset No. 32 spool and one 24 VDC solenoid.

Operating Configuration

The A suffix specifies a spring-offset A arrangement. With the standard solenoid assembly, energizing the coil establishes P-to-B flow. Removing the command allows the spring to return the spool to its normal position.

This model must not be confused with the 32C version. The 32C valve is a three-position, spring-centered, double-solenoid valve, while the 32A model is a two-position single-solenoid valve.

Technical Specifications

BrandTOKYO KEIKI / TOKIMEC
ModelDG4M4-32A-24DC-20-JA
Valve TypeMiniature wet-armature solenoid directional valve
Spool TypeNo. 32 spool with closed-center transition
Operating ArrangementTwo-position, spring-offset A type
Solenoid ArrangementSingle solenoid
Standard Energized FlowP to B
Coil Voltage24 VDC
Electrical ConnectionStandard two-connector arrangement without optional indicator lamp
Maximum Working Pressure21 MPa
Maximum FlowUp to 20 L/min, depending on pressure and flow path
Allowable Tank-Port Back Pressure7 MPa
Mounting MethodGasket mounting
Design Number20
Specification SuffixJA

Installation Notes

  • Use a 24 VDC power supply; do not use a 100 VAC supply.
  • Keep the wet-armature valve filled with hydraulic oil during operation.
  • Prevent excessive surge pressure in the tank line.
  • Maximum permissible flow depends on pressure and hydraulic routing.
  • The standard model does not include the optional M14 indicator lamp and surge suppressor.

Selection and Ordering Notes

Confirm the complete 32A-24DC-20-JA code and the physical nameplate before shipment. Online listings occasionally contain voltage-description errors, so the written sales description alone should not be used to identify the coil.

A 32C valve is not a direct functional substitute because it uses a three-position double-solenoid arrangement. Also verify any LH, M14, PG or special-feature suffix before selecting a replacement.
