High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination
High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination
High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination
High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination
Specifications
Brand Name :
Desun
Model Number :
DS-260158
Certification :
CE RoHS
Place of Origin :
China
MOQ :
1
Price :
Contact Us for the Price
Payment Terms :
T/T, Western Union
Supply Ability :
10000Pcs per Day
Delivery Time :
10-25 days.
Packaging Details :
Neutral Package
Product Name :
Red Colar Sunpower solar panel
Dimension :
260*158mm
Applications :
Lighting, IoT, Electronic Products
Frame :
Aluminum Frame
Solar Cell Brand :
SunPower
Colar :
Red
OEM Services :
YES
Customized :
YES
Description

High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination

1. High Efficiency and reliable quality:

SunPower cells produce 25-35% more power compared to Conventional Cells1 with outstanding aesthetics.The unique all-back-contact cell technology makes the SunPower cell are more efficient because they use available sunlight that others waste. It maximizes the use of available sunlight by exposing the entire front surface of the cell to the sun. Besides, their special structure and manufacturing process such as an anti-reflective coating to the front surface of the cells also make it capture more of the sun’s light.

Our SunPower Monocrystalline Solar Panel adopts high-efficiency SunPower cells which ranking in the top of the solar cell makers.

High Efficiency Sunpower Solar Panels Custom Red Frosted PET Lamination

2. Features

The Sunpower cell has features such as Maximum light capture, Reduced resistive losses, Minimum recombination loss, and improved material absorption. All these characteristic make it has a high efficiency of 21% to 24%.

Dimension(MM) Power(W) Operating Voltage(V) Operating Current(MA) Open-circuit Voltage(V) Short-circuit Current(MA)
148*65*1.6 1.4 5.0 280 6.5 290
150*40*0.8 0.6 5.5 105 6.4 110
150*76*2.4 1.5 5.5 272 6.4 285
150*135*3 2.6 6.0 430 7.1 450
170*170*2.0 3.0 5.5 540 6.4 560
175*166*3.3 4.0 5.0 800 6.5 820
180*115*3 3.0 6.0 500 7.1 525
183*65*2 1.0 5.5 174 6.5 185
221*182*3 5.4 5.5 980 6.5 1000
235*135*2.4 4.0 5.0 800 6.5 820

3. Applications:

Our Sunpower Solar Panel can reach to around 21% to 24% efficiency. And PET / ETFE lamination available, we can make it a flexible design or fixed design base on your need and different applications. This kind of solar panel can be widely used for different places such as solar mobile phone, Bluetooth headsets, GPS, wearable devices, IOT, active FRID, solar lamp, boats, cars, caravans, bus, RV etc.
