Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Specifications
Brand Name :
Bently Nevada
Model Number :
991-01-XX-01-CN
Place of Origin :
USA
MOQ :
1
Price :
66USD
Payment Terms :
T/T
Supply Ability :
in stock
Delivery Time :
2-3 work days
Packaging Details :
Brand new and original
Product Model :
991-01-XX-01-CN
Estimated Shipping Size :
10x7.5x6cm
Manufacturer :
Bently Nevada
Operating Temperature :
-35°C to +85°C (-31°F to +185°F)
Storage Temperature :
-51°C to +100°C (-60°F to +212°F)
Shipping :
TNT, DHL, FedEx, EMS, UPS
MOQ :
1 piece
Packaging :
Original new packaging
Description
991 Thrust Transmitter — Product Overview
Bently Nevada 991-01-XX-01-CN Thrust Transmitter with 4-20 mA Signal Output
Product Name 991 Thrust Transmitter
Intended Use Designed primarily for OEMs of centrifugal air compressors, small pumps, motors, or fans requiring a simple 4-20 mA proportional axial displacement (thrust) signal for machinery control systems.
Signal Output 4-20 mA industry-standard signal proportional to shaft axial position.
Transmitter Type 2-wire, loop-powered device
Compatible Sensor 3300 NSv Proximity Probe
Extension Cable Options 5 m and 7 m system length
Functionality Conditions input from the proximity probe into appropriate engineering units and provides output for machine protection alarming and control logic.
Power Supply Loop-powered (2-wire)
Applications Machinery control systems requiring axial displacement monitoring; suitable for centrifugal air compressors, pumps, motors, and fans.
Environmental Considerations Designed for industrial environments; supports rugged installation with compact footprint.
Key Features of the 991 Thrust Transmitter
Integrated Design: Built-in Proximitor Sensor eliminates the need for an external unit.
Diagnostic Outputs: Non-isolated "PROX OUT" and "COM" terminals Coaxial connector providing dynamic vibration and gap voltage outputs for diagnostics.
Easy Calibration: Zero and span potentiometers (non-interacting) located under the transmitter label for convenient loop adjustment.
Quick Testing: Test Input pin enables rapid loop output verification using a variable DC voltage source.
Power Protection: Power-up inhibit circuit prevents signal errors caused by line voltage transients.
Fault Protection: Not OK / Signal Defeat circuit prevents false alarms and high outputs due to probe faults or loose connections.
Flexible Installation: Supports DIN-rail or bulkhead mounting--both included as standard options.
Rugged Construction: Fully potted housing ideal for high-humidity environments (up to 100% condensing).
Space-Efficient: Compatible with 3300 NSv proximity probes, allowing installation in tight or restricted spaces.
