Screw terminals Keystone 7774 with brass tin plate terminals and nickel plated binding head screws
Screw terminals Keystone 7774 with brass tin plate terminals and nickel plated binding head screws
Specifications
Ontology Coating :
-
Current Rating :
-
Body Material :
-
Number of Leg :
-
Description :
Through Hole Screw Connectors RoHS
Mfr. Part # :
7774
Package :
Through Hole
Model Number :
7774
Description

Screw Terminals

These easy-to-mount, multipurpose screw type terminals offer a practical, low-cost alternative to PC screw type edge connectors, barrier blocks, terminal boards, and terminal strips. They are steadfast and easy to install, accommodating solid or stranded wire, crimp type terminals, or lugs. The low-profile, multi-placement design makes them ideally suited for high-density packaging. They are available unassembled or with the screw installed and captivated. Key features include a stable, no-rock design with an exclusive anti-rotational feature, easy mounting with four legs into pre-drilled or punched holes, and accessibility for PC board testing. The binding screw is positioned above board level to prevent wicking during wave soldering.

Product Attributes

  • Material: Terminals are made of Brass with Tin Plate. Binding Head Screw is Brass with Nickel Plate.
  • Certifications: ISO 9001 CERTIFIED, RoHS COMPLIANT
  • Color: Color-coded screws available (add color screw suffix to Cat. No.). Suffixes: RED -2, BLACK -3, WHITE -4, BLUE -5, GREEN -6, YELLOW -7. Nickel is the default (no suffix).

Technical Specifications

CategoryModelRatingWire GaugeScrew TypeTerminal MaterialScrew MaterialMounting Type
Screw Terminals7780 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/AHorizontal
Screw Terminals7691 (Unassembled)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel PlateHorizontal
Screw Terminals7693 (Installed & Captivated)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel PlateHorizontal
Screw Terminals7782 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/AVertical
Screw Terminals8191 (Unassembled)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel PlateVertical
Screw Terminals7701 (Installed & Captivated)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel PlateVertical
Screw Terminals7779 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/A45 Mini
Screw Terminals7690 (Unassembled)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel Plate45 Mini
Screw Terminals7692 (Installed & Captivated)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel Plate45 Mini
Screw Terminals7781 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/A45 Mini
Screw Terminals8190 (Unassembled)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel Plate45 Mini
Screw Terminals7700 (Installed & Captivated)15 Amps14-22 AWG6-32 x .250 L.Brass, Matte Tin PlateBrass, Nickel Plate45 Mini
Screw Terminals7783 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/ASnap-in PC Mount
Screw Terminals8189 (Unassembled)15 Amps14-22 AWG4-40 X .250 L.Brass, Matte Tin PlateBrass, Nickel PlateSnap-in PC Mount
Screw Terminals7702 (Installed & Captivated)15 Amps14-22 AWG4-40 X .250 L.Brass, Matte Tin PlateBrass, Nickel PlateSnap-in PC Mount
Screw Terminals7774 (No Screw)15 Amps14-22 AWGN/ABrass, Matte Tin PlateN/ASnap-in PC Mount
Screw Terminals7773 (Unassembled)15 Amps14-22 AWG4-40 X .250 L.Brass, Matte Tin PlateBrass, Nickel PlateSnap-in PC Mount

2410121840_Keystone-7774_C238167.pdf
