PC mount screw terminals with brass nickel plated screws and serrated surface including Keystone 8199
PC mount screw terminals with brass nickel plated screws and serrated surface including Keystone 8199
Specifications
Ontology Coating :
-
Current Rating :
-
Body Material :
-
Number of Leg :
-
Description :
Through Hole Screw Connectors RoHS
Mfr. Part # :
8199
Package :
Through Hole
Model Number :
8199
Description

Product Overview

Keyelco screw terminals offer a compact, heavy-duty design with six snap-in legs for enhanced stability. The serrated top surface ensures a secure connection. These terminals are available in various configurations, including PC mount and vertical types, with options for screw inclusion and color-coding for easy identification and troubleshooting.

Product Attributes

  • Brand: Keyelco
  • Certifications: RoHS COMPLIANT, ISO 9001 CERTIFIED
  • Color Coding: Available for screws (add suffix to Cat. No.)

Technical Specifications

CategoryCatalog NumberRatingTerminal MaterialScrew TypeScrew MaterialScrew SizeMountingNotes
PC Screw Terminals778415 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountNo Screw Supplied
PC Screw Terminals819815 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountScrew Supplied Unassembled
PC Screw Terminals777815 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountScrew Installed & Captivated
PC Screw Terminals778515 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountNo Screw Supplied
PC Screw Terminals819515 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountScrew Supplied Unassembled
PC Screw Terminals777515 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.PC MountScrew Installed & Captivated
PC Screw Terminals778730 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.PC MountNo Screw Supplied
PC Screw Terminals819630 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.PC MountScrew Supplied Unassembled
PC Screw Terminals778630 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewStainless Steel10-32 x .375 [9.5] L.PC MountNo Screw Supplied
PC Screw Terminals819730 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewStainless Steel10-32 x .375 [9.5] L.PC MountScrew Supplied Unassembled
PC Screw Terminals819930 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewStainless Steel10-32 x .375 [9.5] L.PC MountScrew Installed & Captivated
Vertical Type778915 Amps.032 (.81) Brass, Matte Tin PlateCombination drive, binding head screwBrass, Nickel Plate6-32 x .250 [6.3] L.VerticalNo Screw Supplied
Vertical Type769715 Amps.032 (.81) Brass, Matte Tin PlateCombination drive, binding head screwBrass, Nickel Plate6-32 x .250 [6.3] L.VerticalScrew Supplied Unassembled
Vertical Type769915 Amps.032 (.81) Brass, Matte Tin PlateCombination drive, binding head screwBrass, Nickel Plate6-32 x .250 [6.3] L.VerticalScrew Installed & Captivated
Low Profile Vertical Type779130 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.VerticalNo Screw Supplied
Low Profile Vertical Type817430 Amps.032 (.81) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate6-32 x .250 [6.3] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7692-730 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7693-530 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7700-330 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7775-430 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7778-730 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty7699-630 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
Extended Heavy Duty770130 Amps.045 (1.14) Brass, Matte Tin PlateBinding Head ScrewBrass, Nickel Plate10-32 x .375 [9.5] L.VerticalScrew Supplied Unassembled
