3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
3M MP2-R030-51P1-LR
Specifications
Delivery Time :
18-23周
Stock :
2352000
Brand Name :
MP2-R030-51P1-LR
MOQ :
2352
Description :
Specialized Connectors RoHS
Model Number :
MP2-R030-51P1-LR
Packaging Details :
-
Description

Product Overview

The 3M MetPak 2-FB Inverse Socket is a 2 mm, 5-row vertical socket designed for backplane applications. It features a guiding alignment feature to prevent bent pins and is footprint compatible with standard Futurebus+. Ideal for hot-swapping, this socket offers end-to-end stackability and an offset dual-beam contact to minimize insertion force. It mates with MP2-P and MP2-PS Series and includes rear plug-up tails for midplane applications. Compliance information is available in the Regulatory Information Appendix (RIA) on www.3Mconnectors.com.

Product Attributes

  • Brand: 3M
  • Product Line: MetPak
  • Series: MP2 Series
  • Type: Inverse Socket
  • Pitch: 2 mm
  • Rows: 5
  • Orientation: Vertical
  • Termination Style: Solder or Press-Fit Tail
  • Insulation Material: High Temp LCP
  • Insulation Flammability: UL 94V-0
  • Insulation Color: Beige
  • Contact Material: Copper Alloy
  • Contact Underplating: 50 " [1.27 m] Nickel
  • Certifications: UL File No.: E68080
  • Regulatory Compliance: RIA E1 & C1 apply
  • Standard: Footprint compatible with standard Futurebus+; Refer to IEC 61076-4-104 Futurebus+ global standard.

Technical Specifications

Specification Details
Current Rating (Signal) 1.5 A All contacts simultaneously
Insulation Resistance 103 M
Withstanding Voltage 1000 VAC
Temperature Rating -55C to +125C
Tail Termination Option Solder Tail / Press-Fit Tail
Tail Length (Contact-to-PC Board) 4.35 mm [0.171 in] (Solder) / 4.48 mm [0.176 in] (Press-Fit)
Connector Dimensions (Dim. A for Pin Count) 030: 11.95 mm [0.471 in]
060: 23.95 mm [0.943 in]
090: 35.95 mm [1.415 in]
120: 47.95 mm [1.889 in]
150: 59.95 mm [2.36 in]
180: 71.95 mm [2.833 in]
210: 83.95 mm [3.305 in]
240: 95.95 mm [3.778 in]
270: 107.95 mm [4.251 in]
300: 119.95 mm [4.722 in]
Connector Dimensions (Dim. B for Pin Count) 030: 10.00 mm [0.394 in]
060: 22.00 mm [0.866 in]
090: 34.00 mm [1.339 in]
120: 46.00 mm [1.811 in]
150: 58.00 mm [2.283 in]
180: 70.00 mm [2.756 in]
210: 82.00 mm [3.228 in]
240: 94.00 mm [3.701 in]
270: 106.00 mm [4.173 in]
300: 118.00 mm [4.646 in]
Plating Options (Suffix KR) Press-Fit Tails: 0.76 m [30 "] Min. Au Contact Area, 2.54 m [100 "] Min. Matt Whisker Mitigating Sn Tail Area, 1.27 m [50 "] Min. Ni all over
Solder Tails: 0.08 m [3 "] Min. Au Contact Area, 0.67 m [27 "] Min. PdNi Contact Area, 2.54 m [100 "] Min. Matt Whisker Mitigating Sn Tail Area, 1.27 m [50 "] Min. Ni all over
Plating Options (Suffix LR) Press-Fit Tails: 0.08 m [3 "] Min. Au Contact Area, 0.67 m [27 "] Min. PdNi Contact Area, 2.54 m [100 "] Min. Matt Whisker Mitigating Sn Tail Area, 1.27 m [50 "] Min. Ni all over
Solder Tails: 0.08 m [3 "] Min. Au Contact Area, 0.67 m [27 "] Min. PdNi Contact Area, 2.54 m [100 "] Min. Matt Whisker Mitigating Sn Tail Area, 1.27 m [50 "] Min. Ni all over
Contact Loading Pattern 1 = All rows filled
2 = Rows A, B, C and D filled, Row E omitted
PCB Hole Mounting Pattern (Finished Dia. D) 0.700-0.800 mm [.0276-.0315 in]
PCB Hole Mounting Pattern (Drilled Hole Dia.) 0.830-0.860 mm [.0330-.0340 in] or 0.85 mm [#66] TWIST DRILL

Send your message to this supplier
