The SX38-8PFS highly watertight slip ring is specially developed for underwater use and various harsh working environments. Different protection levels can be selected according to the different uses of the slip ring. The underwater signal dedicated waterproof slip ring (watertight ring) can work stably at 5 meters underwater and is suitable for underwater sonar rotating probes. It focuses on signal transmission without load-bearing.

SX38-8PFS highly watertight slip ring Features

1. Four built-in RG179 coaxial cables are optimized for high-frequency signal transmission. They can transmit high-definition images or high-speed data in underwater sonar and communication equipment with a signal attenuation rate of less than 0.5dB/m.
2. It specifically supports underwater operation up to 5 meters. The reinforced sealing structure of the coaxial cable terminals prevents short circuits caused by water leakage at the signal cable interface in rotating lenses of underwater photography equipment.
3. The 4-channel signal + 4-channel shielding design, with a shielding coverage rate of 95%, effectively isolates electromagnetic interference generated by underwater motors and solenoid valves. In precision underwater measurement instruments, the measurement accuracy error is ≤0.1mm.
4. The rotor wire length is customizable, allowing connection between underwater rotating components and surface control terminals without additional wiring, simplifying wiring in shallow water equipment.
5. The rated voltage is 24V, suitable for low-voltage safety scenarios. Even if the wire is damaged, it reduces the risk of electric shock and improves underwater operation safety.

SX38-8PFS highly watertight slip ring parameters

SX38-8PFS highly watertight slip ring application scenarios

Mainly used in underwater robots, marine exploration equipment, oil field drilling, chemical production lines, water treatment plants, aerial work vehicle rotating platforms, hydrographic buoys, large irrigation turntables, offshore wind power operation and maintenance ships, pickling production lines, beer machines, filling machines, etc.
