Specifications
Brand Name :
Comelink
Model Number :
QDD-4X100G-FR-4Si
Certification :
ROHS/ISO9001/CE
Place of Origin :
China
MOQ :
1 PC
Price :
USD 700 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5 workdays
Part Number :
QDD-4X100G-FR-4Si
Form Factor :
QSFP-DD
Max Data Rate :
425Gbps
Wavelength :
1310nm
Max Distance :
2km
Connector :
MPO-12/APC
Warranty :
3 Years
Package Dimensions :
5.12 x 3.54 x 1.57 inches
Description

QSFP-DD 4 x 100G FR PAM4 Optical Transceiver Module (1310nm MTP/MPO-12 SMF 2km with FEC DDM)

QSFP-DD 4*100Gbps transceiver module is designed for optical communication applications in 400 Gigabit Ethernet links over 2km single mode fiber. This product has 8 independent electrical input/output channels which can convert 50Gbps (PAM4) electrical input data to 4 channels of 100Gbps (PAM4) parallel optical signals. Also, it converts 4 channels of parallel optical signals of 100Gbps (PAM4) for each channel into 8 channels of 50Gbps (PAM4) electrical output data. The module incorporates 4 parallel channels on a 1310nm center wavelength, operating at 100G per channel. The electrical interface of the module is compliant with the 400GAUI-8 interface as defined by IEEE 802.3bs, and compliant with QSFP-DD MSA.

Feature:

  • Built-in Marvell DSP Chip, Max Power Consumption ≤12W.
  • Provide Professional Compatibility and Parameter Test Reports.
  • Compliant with Hot Pluggable QSFP-DD MSA, IEEE 802.3bs Standard.
  • Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
  • DDM(Digital Diagnostic Monitoring) Supported.
  • 30-Day Free Return, 1-Year Free Replacement, 3-Year Warranty, Lifetime After-sales Technical Support.

Quality Assurance

Excellent quality is the foundation of Comelink's survival and development. Our operation team are experts with many years' experience in the optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Specificiation

P/N QDD-4X100G-FR-4Si Vendor Name Comelink
Form Factor QSFP-DD Max Data Rate 425Gbps
Wavelength 1310nm Max Distance 2km
Modulation Format PAM4 Host Required FEC
Connector MTP/MPO-12 Voltage Supply 3.3V
Cable Type SMF DDM Support Yes
Transmitter Type Silicon photonics Receiver Type PIN
TX Power -2.4~+4.0dBm Receiver Sensitivity < -4.5dBm
Operation Temperature 0 to 70°C (32 to 158°F) Maximum Power < 10W
Protocols QSFP-DD MSA,
100G Lambda MSA 100G-FR		 Application 400G Ethernet, Data Center Interconnect, Infiniband Interconnects

Application:

Comelink QDD-4X100G-FR-4Si QSFP-DD 4 x 100G FR PAM4 1310nm 2km MTP/MPO-12 SMF FEC CMIS4.0 Silicon photonics Optical Transceiver Module

Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
Comelink QDD-4X100G-FR-4Si QSFP-DD 4 x 100G FR PAM4 1310nm 2km MTP/MPO-12 SMF FEC CMIS4.0 Silicon photonics Optical Transceiver Module

Unleash HPC Power with InfiniBand Architecture

We provides the Infiniband network solution, offering significant advantages in terms of high-speed, low latency, scalability, and efficiency.

Comelink QDD-4X100G-FR-4Si QSFP-DD 4 x 100G FR PAM4 1310nm 2km MTP/MPO-12 SMF FEC CMIS4.0 Silicon photonics Optical Transceiver Module

Flat Top OSFP Connector Shell

The OSFP shell has a flat top and is used in adapters, such as ConnectX-7 InfiniBand Adapter Cards.
