Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module
Specifications
Brand Name :
Comelink
Model Number :
QSFP-DD-2x100G-LR4
Certification :
ROHS/ISO9001/CE
Place of Origin :
China
MOQ :
1 PC
Price :
USD 1200 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5 workdays
Part Number :
QSFP-DD-2x100G-LR4
Form Factor :
QSFP-DD
Max Data Rate :
200Gbps
Wavelength :
1310nm
Max Distance :
10km
Connector :
Dual CS
Warranty :
3 Years
Package Dimensions :
5.12 x 3.54 x 1.57 inches
Description

2x100GBASE-LR4 QSFP-DD Optical Transceiver Module (1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm CS SMF 10km DDM)

QSFP-DD 2x100GBASE-LR4 optical transceiver modules are suitable for data centers and HPC (High-Performance Computing) links up to 10km over single-mode fiber. It also features outstanding BER and high sensitivity because of its reliable design and excellent coupling efficiency.

Feature:

  • Built-in Marvell DSP Chip, Max Power Consumption ≤8W.
  • Provide Professional Compatibility and Parameter Test Reports.
  • Compliant with Hot Pluggable QSFP MSA, IEEE 802.3bs Standard.
  • Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
  • DDM(Digital Diagnostic Monitoring) Supported.
  • 30-Day Free Return, 1-Year Free Replacement, 3-Year Warranty, Lifetime After-sales Technical Support.

Quality Assurance

Excellent quality is the foundation of Comelink's survival and development. Our operation team are experts with many years' experience in the optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Specificiation

P/N QSFP-DD-2x100G-LR4 Vendor Name Coemlink
Form Factor QSFP-DD Max Data Rate 212.5Gbps
Wavelength 1295.56nm, 1300.05nm
1304.58nm, 1309.14nm		 Max Distance 10km
Connector Duplex CS Voltage Supply 3.3V
Cable Type SMF DDM Support Yes
Transmitter Type DML LWDM4 Receiver Type PIN
TX Power Each Lane Receiver Sensitivity < -8.6 dBm
Operation Temperature 0 to 70°C (32 to 158°F) Maximum Power < 8W
Protocols SFF-8665 CMIS 3.0
QSFP-DD MSA		 Application 100G Ethernet

Feature:

Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module

Unleash HPC Power with InfiniBand Architecture

We provides the Infiniband network solution, offering significant advantages in terms of high-speed, low latency, scalability, and efficiency.

Comelink QSFP-DD-2x100G-LR4 2x100GBASE-LR4 QSFP-DD LWDM4 10km Duplex CS SMF Optical Transceiver Module

Flat Top OSFP Connector Shell

The OSFP shell has a flat top and is used in adapters, such as ConnectX-7 InfiniBand Adapter Cards.
