230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor
Specifications
Place of Origin :
Jiangsu
Brand Name :
DHH
Model Number :
DC-50A
Packaging Details :
Wooden box
Supply Ability :
600set/months
Price :
Negotiate
Certification :
CE/ISO9001
MOQ :
1set
Delivery Time :
25days
Payment Terms :
T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Product name :
air screw compressor
Voltage :
380V/220V or Customized
Capacity :
173~230cfm, 4.9 to 6.5m3/min
Pressure :
7bar 8bar 10bar 13bar
Type :
Screw
Configuration :
Stationary
Dimension(L*W*H) :
1500*940*1415 mm
Weight :
655kg
Application :
General Industry
Air end :
Hanbell/Rotorcomp
Motor energy efficiency class :
IE3/IE4
Motor protection class :
IP54/IP55
Cooling method :
Air Cooling
OEM :
Avaliable
Description

High Efficiency 8bar 10bar 13bar Fixed Speed 37kw Industrial Screw Air Compressor

Product feature

1. Hanbell Air End
●Hanbell air end, Reached National Level 1 Energy Efficiency Standard.
●SAP type line to maximize the screw compression efficiency Similar products save more than 5%
●High machining accuracy, low vibration of main machine and low noise.


2. High-quality Motor
●High-efficiency motors with energy efficiency
levels of IE2 / IE3 and protection levels of IP54 / IP55.
Efficient design, SKF bearings, ensure the long life of the motor.


3.L arge Touch Master Controller
●Matching inverter exclusive customization.
●LCD Chinese and English switch display.
●Rich self-diagnostic functions such as fault alarm, maintenance reminder, automatic shutdown, etc.
●Clock function, can set timing switch.
●Multiple signal outputs: RS485 port.
●High machining accuracy, low vibration of main machine and low noise.

Specifications

Our direct driven fixed speed screw air compressors parameter list:

Model Air Delivery (m3/min) Power (kW) Noise (Db) Outlet diameter Dimension (mm) Weight (Kg)
0.7Mpa 0.8Mpa 1.0Mpa 1.3Mpa Length Width Height
DC-10A 1.3 1.2 1 / 7.5 63 G3/4 895 590 970 190
DC-20A 2.4 2.3 2 / 15 65 G3/4 1062 690 1000 236
DC-30A 3.7 3.6 3.2 2.8 22 68 G1 1330 830 1265 400
DC-40A 5.2 5 / 3.3 30 68 G1 1330 830 1265 500
DC-50A 6.5 6.2 5.6 4.9 37 69 G1 1/2 1500 940 1415 655
DC-60A 8.0 7.3 6.0 5.9 45 70 G1 1/2 1500 940 1415 730
DC-75A 10.1 9.5 8.7 7.3 55 70 G2 1600 1060 1470 945
DC-100A 13.6 12.8 11.3 9.2 75 72 G2 2000 1120 1590 1291
DC-125A 16.1 15.5 13.6 12.5 90 72 G2 2000 1120 1590 1421
DC-150A 21.2 19.6 17.8 15.5 110 72 DN65 2400 1630 1980 2170
DC-175A 24.1 23.2 19.5 17.8 132 72 DN65 2400 1630 1980 2350
DC-220A 28.8 27.8 23.0 20 160 72 DN80 2800 1828 2150 3620
DC-250A 32.5 31.2 27.5 25.8 185 72 DN80 2800 1828 2150 3920
DC-275A 34.5 34.0 30.5 28.0 200 76 DN80 2800 1828 2150 4200
DC-300A 36.8 34.7 31.5 29.5 220 76 DN100 4260 2182 2170 4800
DC-350A 43.0 41.5 38.0 34.9 250 76 DN100 4260 2182 2170 5200
DC-375A 51.3 50.6 46.0 41.5 280 82 DN100 4360 2150 2258 7500
DC-420A 56.8 55.9 50.1 42.0 315 82 DN125 4360 2150 2258 7500
DC-420W 56.8 55.9 50.1 42.0 315 82 DN125 3800 2200 2250 7200
DC-475A 66.1 65.4 55.1 46.0 355 85 DN125 4600 2240 2260 9000
DC-475W 66.1 65.4 55.1 46.0 355 82 DN125 3800 2200 2250 8570

1.A represents air-cooling type,W represents water-cooling type;

2.Working Environment temperature: -5ºC~45ºC;
3.Discharge temperature is less than ambient temperature +10ºC~15ºC;

4.Drive Mode: coupling direct driven;
5.Startup Mode: direct start under 11kw, and above 11kw;
6.Work Power: 380V / 50HZ, other voltages can be made for customers;
7.F.A.D volume flow test is according to ASMC PTC9 or ISO1217 standard (GB/T3853)

230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor

230cfm Industrial Screw Air Compressor 37kw 8 Bar Fixed Speed Compressor

Factory workshop

DHH Screw Compressor Co. Ltd was founded in 1996, is a high-tech enterprise specialized in the R&D and the production of screw type air compressor, Chinese has established two manufacturing base (Shanghai DHH, and DHH Jiangsu ) to provide various types of screw air compressors for users around the world.DHH give you quality guaranty for all products, good after-sale and lifelong maintenance. Welcome to choose us as your partner and best supplier! Now we have fixed speed (belt driven and direct driven) screw air compressor; VSD variable speed frequency screw air compressor, permanent magnet frequency screw compressor and two stage double screw air compressor etc.

FAQ

Q1:Are you factory or trading company?

A1: We are factory.

Q2:Where is your factory located? How can I visit there?

A2: Our factory is located in Qidong City, Jiangsu Province, China. We can pick up you from Shanghai, it’s about 1 hour from Shanghai Pudong Airport to our factory. Warmly welcome to visit us!

Q3: Will you provide some spare parts of the machines?

A3: Yes, of course.

Q4: Warranty terms of your machine?

A4: Two years warranty for Air End, one year for spare part.

Q5: How long will you take to arrange production?

A5:380V 50HZ we can delivery the goods within 14 days. Other electricity or other color we will delivery within 22 days.

Q6:How does your factory do regarding quality control?

A6:Quality is everything. we always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001:2015 authentication and CE certificate.

Q7: Can you accept OEM orders?

A7: Yes, with professional design team, OEM orders are highly welcome.
