8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors
Specifications
Place of Origin :
Jiangsu
Brand Name :
dhh
Certification :
CE/ISO9001
Packaging Details :
Wooden box
Supply Ability :
600 set/month
Price :
Negotiate
MOQ :
1 SET
Delivery Time :
25 days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product name :
diesel compressor
Configuration :
Stationary
Power Source :
Diesel
Lubrication Style :
Lubricated
Mute :
Yes
Voltage :
380V/50hz or customer's requirement
Dimension(L*W*H) :
1100x800x980mm
Weight :
1550kg
Warranty :
1 Year
Working Pressure :
8 bar
Gas Type :
Air
Application :
for mining
Pressure :
7bar to 22 bar
Engine :
YuChai
Capacity :
4 to 27 m3/min
Control Panel :
Deluxe mircro-computer florescence
Power :
42 to 295 kw
Keyword :
diesel air compressor
After Warranty Service :
Online support
Description

8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors

Diesel driven air compressor features:
1. High reliability: The compressor has few parts and no wearing parts, so it operates reliably, has a long life, and the interval between overhauls can reach 40,000 to 80,000 hours.
2. Convenient operation and maintenance: high degree of automation, operators do not need to undergo long-term professional training, and can realize unattended operation.
3. Good power balance: no unbalanced inertial force, stable high-speed operation, no foundation operation, small size, light weight, and less floor space.
4. Strong adaptability: It has the characteristics of forced gas transmission, the volume flow is almost not affected by the exhaust pressure, and can maintain high efficiency in a wide range of speed.

Portable diesel screw air compressors parameter list:

Model No. Wheels

Air flow

m3/min

Pressure

/Mpa

Power

kw

 Engine

weight

(kg)

 Dimensions(mm)
42SCG-7 Stationary 4 0.7 42kw Quanchai 780 2110x1500x1620
50SCY-7 2 wheels 6 0.7 58kw Yuchai 1050 2532x1682x1684
58DHY-8 2 wheels 7 0.8 58kw Yuchai 1550 3140x1740x1900
110DHY-8 4 wheels 12 0.8 110kw Yuchai 2480 3120x1630x2290
110DHY-10 2wheels 12 1.0 110kw Yuchai 2260 2890x2020x2270
110DHY-14.5 2 wheels 10 1.45 110kw Yuchai 2130 2890x2020x2270
138DHY-14.5 2wheels 13 1.45 140kw Yuchai 3000 3350x2060x2350
139DHY-13 4wheels 15 1.3 140kw Yuchai 3000 3650x1700x2040
177DHY-17 4wheels 16 1.7 179kw Yuchai 3800 3720x1970x2250
180DHY-8 4wheels 20 0.8 179kw Yuchai 3800 3720x1970x2250
198DHY-18 4wheels 18 1.8 191kw Yuchai 3900 3720x1970x2550
195DHY-19 4wheels 19 1.9 194kw Yuchai 3830 3720x1970x2550
260DHY-21 4wheels 22 2.1 260kw Yuchai 4590 4150x2000x2900
288DHY-22 4wheels 27 2.2 295kw Yuchai 4910 4150x2000x2900

Project case

8 Bar Portable Diesel Air Compressor Stationary Small Screw Compressors

Why choose us?

1.Quality Guarantee
With more than 24 years industry experience and our compressor approved by CE, ISO9001, SGS, And TUV test.The raw materials are strictly inspected and Some key parts are imported from overseas.Each compressor must pass at least 5 hours of continuous testing before leaving the factory.

2.Warranty Period
The complete machines are proviede with one-year warranty, and the compressor air end with Two-year warranty and lifetime maintenance(With the exception of wearing parts)

3. Installation and Commissioning
Provied customers with installation and commissioning instructions,and all service-providing personnel are strictly trained technically by our company.

4.After -sales Services
Our company has service network in world, giving prompt replies to customers after notified within 24~48hours for troubleshooting.

5.Spare Parts
Our company always supply spare parts on most favorable terms.
