Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
Specifications
Place of Origin :
CN
Brand Name :
TYANSHINE
Certification :
ISO9001:2008 SGS RoHS
Model Number :
TX-1212RGBW/RGBL
MOQ :
1000pcs
Price :
Negotiation
Packaging Details :
In Reel
Delivery Time :
5-10 days
Payment Terms :
ExW, FOB, CIF
Supply Ability :
100000PCS/month
Color :
4in1 RGBW / RGBL
Power :
120Watt / 180Watt
Package size :
1.2x1.2cm
Substrate :
Ceramic
Cetification :
RoHS Reach
Description

Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs

Features:

  1. Small size, high power Ceramic SMD Package,
  2. Lower thermal resistance, higher light efficiency
  3. Ceramic base with good heat conductivity to enlarge the lifespan
  4. Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
  5. SMD Components suitable for reflow-solidering,
  6. Low expansion coefficient, high air tightness

Specifications:

120Watt 4in1 RGBW

Color Vf (V) Max. If (mA) λd(nm)
CCT(K)

φv(lm)

IF=1000mA

Red 2.4-3.2V 5000mA x 2 620-627nm 230-290lm
Green 3.2-4.0V 5500mA x 2 527-532nm 680-850lm
Blue 3.0-3.8V 6000mA 450-455nm 60-80lm
Cool White 3.0-3.8V 5000mA x 2 5700-6500K 800-900lm

120Watt 4in1 RGBL

Color Vf (V) Max. If (mA) λd(nm)
CCT(K)

φv(lm)

IF=1000mA
Red 2.4-3.2V 5000mA x 2 620-627nm 230-290lm
Green 3.2-4.0V 5500mA x 2 527-532nm 680-850lm
Blue 3.0-3.8V 6000mA x 1 450-455nm 60-80lm
Lime 3.0-3.8V 5000mA x 2 4250-4500K 820-1000lm

180Watt 4in1 RGBW

Color Vf (V) Max. If (mA) λd(nm)
CCT(K)

φv(lm)

IF=1000mA
Red 6.0-7V 5000mA 620-625nm 360-500lm
Green 7.5-8.5V 5500mA 527-532nm 900-1200lm
Blue 8.3-9.3V 6000mA 452-457nm 145-185lm
Cool White 8.3-9.3V 5000mA 5700-6500K 1100-1450lm

180Watt 4in1 RGBL

Color Vf (V) Max. If (mA) λd(nm)
CCT(K)

φv(lm)

IF=1000mA
Red 6.0-7V 5000mA 620-625nm 360-500lm
Green 7.5-8.5V 5500mA 527-532nm 900-1200lm
Blue 8.3-9.3V 6000mA 452-457nm 145-185lm
Lime 8.3-9.3V 5000mA 4150-4400K 800-1100lm

Applications:

Stage Lighting, Beam Wash Flood effects
Architectural lighting

Landscape lighting

Ceramic SMD1212 LED RGBW 120Watt RGBL 180Watt 5000mA Power SMD LEDs
