Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA
Specifications
Brand Name :
TYANSHINE
Model Number :
TX-3535
Certification :
RoHS REACH IEC62471
Place of Origin :
CN
MOQ :
1000pcs
Price :
Negotiation
Payment Terms :
ExW, FOB, CIF
Supply Ability :
100000PCS/month
Delivery Time :
5-10 days
Packaging Details :
In Reel
Color :
R/G/B/C/A/L/A/W
Power :
10W / 12W
Current :
2500mA
PackageSize :
SMD3535
Substrate :
Ceramic
Description

Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA

Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA

Key Features:

  1. Ceramic SMD3535 LED, Flat Lens
  2. Lower thermal resistance, higher light efficiency
  3. Ceramic base with good heat conductivity to enlarge the lifespan
  4. Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
  5. Various options of Colours and CCT range,
  6. Low expansion coefficient, high air tightness

Specifications:

SMD3535 LED 10Watt class, Flat, Rectangular LED die

Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA

Color Vf (V) Max. If (mA) λd(nm)
CCT(K)

φv(lm)

IF=1000mA

 CRI
Red 1.9-2.6V 2500mA 620-625nm 125-160lm
Green 2.7-3.5V 2500mA 522-532nm 250-320lm
Royal Blue 2.8-3.6V 2500mA 450-460nm 40-65lm
Light Blue 2.8-3.6V 2500mA 465-475nm 80-105lm
Cyan 2.8-3.6V 2500mA 485-510nm 250-320lm
Lime 2.8-3.6V 2500mA

4030-4280K

(565-568nm)

 350-450lm
PC-Amber 2.9-3.2V 2500mA

1750-1900K

(587-590nm)

 235-310lm
Cool White 2.8-3.4V 2500mA

5700-6500K

4800-5500K

 350-480lm 70
Neutral White 2.8-3.4V 2500mA 3780-4300K 260-320lm 80
Warm White 2.7-3.4V 2500mA 2870-3130K 265-305lm 80
Warm White 2.7-3.4V 2500mA 2600-2800K 250-300lm 80
Warm White 2.7-3.4V 2500mA 2130-2270K 250-300lm /

SMD3535 LED 12Watt class, Flat, Circular LED die

Ceramic SMD3535 LED 10Watt Red Green Blue White PC-Amber Lime Flat Lens LED 2500mA

Color Vf (V) Max. If (mA) CCT(K)

φv(lm)

IF=1000mA

 LES
Lime 2.9-3.2V 4000mA

4030-4280K

(565-568nm)

 480-630lm

Diameter

1.35mm
Lime 2.9-3.2V 4000mA

5400-5900K

(549-552nm)

 400-600lm
PC-Amber 2.9-3.2V 4000mA

1750-1900K

(587-590nm)

 250-320lm
Cool White 2.9-3.2V 4000mA

6000-7000K

 185-250lm

Applications:

Stage Lighting,

Flashlight;

Automobile Illumination
Architectural lighting

Landscape lighting
