S45C Blackened Fixture Clamping Pressure Plate Durable Tapped Heel Clamp Strap
S45C Blackened Fixture Clamping Pressure Plate Durable Tapped Heel Clamp Strap
Specifications
Brand Name :
ADJIG
Model Number :
CP02
Place of Origin :
Chongqing, China
MOQ :
5
Payment Terms :
L/C,T/T
Supply Ability :
Less than 20 pieces, shipped within 10 days. More than 20 items will be shipped within 15-20 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/Wooden crate
Price :
42-84 USD per item
Model :
CP02
Material :
S45C
Heat Treatment :
HRC 32°-38°
Surface Finish :
Blackened
Description

Durable Tapped-Heel Clamp Strap for CNC Milling Machining Workholding Fixtures

Material: S45C
Heat Treatment: HRC 32°-38°
Surface Finish: Blackened
Advantages: The pressure point features a circular hole, making it most suitable for concave surfaces or curved areas.

Engineered for robust performance in demanding machining environments, this Durable Tapped-Heel Clamp Strap delivers secure and versatile workholding. The unique tapped-heel design provides a positive location point for easy and precise setup, ensuring maximum stability during heavy milling operations. Forged from high-strength steel, it offers exceptional resistance to bending and deformation, guaranteeing long-lasting reliability. Its low-profile design maximizes tool clearance while the strap accommodates a wide range of workpiece heights. An essential component for any CNC fixture, it ensures vibration-free clamping, reduces setup time, and enhances both safety and machining precision for superior results.

Model No. A B C D E F G H J K L M Weight(kg)
CP02-12150 150 38 15 20 70 25 30 18 13 22 7 M12 0.58
CP02-16150 150 48 20 25 40 35 40 24 17 32 5 M16 1.12
CP02-16200 200 90 1.5
CP02-20200 200 60 30 35 60 40 50 26 21 35 6 M20 2.22
CP02-20250 250 110 2.74
