Precision Split V Block Accurate Holding Machining For Round Workpieces
Precision Split V Block Accurate Holding Machining For Round Workpieces
Specifications
Brand Name :
ADJIG
Model Number :
SU14
Place of Origin :
Chongqing, China
MOQ :
5
Payment Terms :
L/C,T/T
Supply Ability :
Less than 20 pieces, shipped within 10 days. More than 20 items will be shipped within 15-20 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/Wooden crate
Price :
126-168 USD per item
Description

Precision Split V Block for Accurate Holding and Machining of Round Workpieces

Material: S45C
Heat Treatment: HRC45
Surface Finish: Blackened
Application: Combined with SU15 to form a V-block.

Support range can be adjusted appropriately based on workpiece dimensions using the alignment holes.

Elevate your precision machining with this essential Precision Split V Block, engineered for the secure and accurate holding of round workpieces. Its innovative split design allows for versatile top and side clamping, ensuring your cylindrical parts—from shafts to pins—are held firmly and concentrically for drilling, milling, and grinding operations. Manufactured from high-grade, hardened steel and meticulously ground to exacting tolerances, it guarantees long-lasting durability and repeatable accuracy. The integrated clamping slots provide seamless compatibility with standard fixture sets. This indispensable tool drastically reduces setup time while eliminating misalignment, making it a cornerstone for any high-accuracy machining or inspection task.

Model No. A B C D E F KG
Max Min
SU14-1250-600 12 M12 22 85 80 600 50 1.85
SU14-1650-600 16 M16 16 85 80 600 50 1.76
