LB2000 160t/H Asphalt Mixing Plant Road Construction
LB2000 160t/H Asphalt Mixing Plant Road Construction
LB2000 160t/H Asphalt Mixing Plant Road Construction
LB2000 160t/H Asphalt Mixing Plant Road Construction
Specifications
Brand Name :
CINACHARM
Model Number :
160t/h asphalt mixing plant
Certification :
CE ISO BV SGS
Place of Origin :
Henan, China (Mainland)
MOQ :
1 set
Price :
500000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
25 working days
Packaging Details :
China Standard Package
Name :
Asphalt mixing plant
Product name :
Stationary Asphalt Mixing Plant
Model :
160t/h
Application :
High-grade Asphalt Road Paving
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturin
Warranty :
12 months
Control System :
full-automatic operation by computer
Color :
Cutomer Request
Voltage :
according to the clients
Description

Asphalt mixing plant LB2000 160t/h road construction asphalt mixing plant

Product overview of asphalt mixing plant LB2000:

The asphalt mixing plant mainly includes cold feeding system, drying system, combustion system, hot material improvement system, vibrating screen,,, hot material storage tank, suspension mixing system, asphalt conveying system, powder conveying system, dust removal system, finished product storage tank, management system and other parts. Vibrating screen driven by imported vibrating motor greatly improves efficiency and reduces equipment failure rate, unique mixing blade design makes mixing easier, reliable and effective with a very dynamic mixing cylinder. Adopt double machine automatic control/manual control system with automatic fault diagnosis program, easy and safe operation.

Main advantages of asphalt mixing plant LB2000:

Energy efficiency.

Thermodynamic design and high energy efficiency, resulting in the lowest energy consumption

Environmental protection.

Environmentally friendly design with high efficiency and reliable baghouse with compact structure and high dust collector efficiency.

High efficiency.

Specially designed double level mixer with strong mixing ability and good effect .

Reliability.

Control system adopts international famous brand, advanced performance and stability, reliable and accurate measurement.

Elegant appearance.

Modular design, beautiful appearance, novel structure, compact distribution, space-saving, easy to assemble and transport.

Parameters of asphalt mixing plant LB2000:

Type LB2000
Production capacity (t/h) 160
Cold aggregate supply system Feeder hopper (pcs) 5
Hopper volume(m3/pc) 10
Loading width(m) 3.3
Drying system Drying drum ×L(m) 2.0x9.0
Driving power(kW) 4x15
Burner capacity(MW) 14
Fuel Diesel, heavy oil or gas
Mixing tower Screening mode Double shaft / Linear screening
Screen driving power (kW) 2x11
Screen layer 5
Hot bin volume (m3) 35
Mixer capacity(kg/batch) 2300
Mixer driving power(kW) 2x37
Filler supply system Stone powder silo volume(m3) 50
Recycled powder silo volume(m3) 20
Dust collection system Dust collection mode Primary gravity dust collection + secondary bag filter pulse cleaning
Filtering area(m2) 600
Bitumen supply system Bitumen tank (pc x m3) 2 x 50
Hot oil furnace (×104kal/h) 60
Total power (kW) 470
Covering area (m x m ) 45x35
Optional End product underneath storage (m3) 30
End product side storage (m3)

50

FAQ

1. Quotation to the customer as fast as possible, provided that we are clear about the capacity, quantity

automation requirements, spare parts requirements (top Chinese brands or world brands such as Siemens Automotive), wearing parts requirements, delivery time, etc.

2. The lowest possible price to the customer.

3. Flexible payment terms.

4. Short processing and production time. For individual machines - no more than 5 days; for production lines - no more than 15 days.

5. Warranty.

The content is for reference only, everything is based on facts!
