Drying System
1. Adopts four sets of famous powerful direct-connected gear motors to drive the drying drum;
2. Optimized blades make the drying process more balance with higher heat utilization rate;
3. Drying drum is covered by thermal insulation material and stainless steel skin to avoid heat loss;
4. Well calculated and carefully heat treated drying drum, world class bearings have long service life and stable performance.

Dust Collecting System
1. Double dust collecting system, European emission standards;
2. Pulsating dust removal method, energy saving and efficient;
3. Durable key components;
4. Safety protection, intelligent inspection.

Vibrating Screen
1. Sturdy and durable, high intensity and remarkable screening effect;
2. Screen mesh easy to maintain and replace, time saving;
3. Frequency and amplitude perfectly matched, over 95% grading precision, competent to any severe working situation, high temperature resistance and excellent productivity;
4. Best design to guarantee the best screening result.
a. Adopts self-synchronizing driving technology, maintenance-free and environmental;
b. Patent enhanced drivable bridge structure design, tough and protective for screening components;
c. Famous vibrating motor.

Mixing System
1. Simulating optimization of material mixing movement speed;
2. Ensures each batch is totally and equally mixed with 25% mixing efficiency enhancement and 20% energy consumption reduction;
3. High productivity double-shaft mixer

i) Mixing cycle time: 40-60s, set up freely

j) Dust removing efficiency: dust emission level≤100mg/Nm3

k) General power consumption: 286Kw Including:

Feed unit 2.2KW×4

Belt conveyer power 4KW×2

Rotary dryer power 7.5KW×4 Burner power 30KW

Hot aggregate elevator power 11KW

Vibration screen motor power 11 KW

Mineral powder screw conveyor power 4KW×2

Recycle screw conveyor power 4KW×3

Fan power 55KW

Air compressor power 22KW

Bitumen pump power 7.5Kw+5.5kW

Hot oil pump 11Kw Others 15Kw

d) Controlling mode: full automatic operation, semi-automatic,manual operating for option.

e) Hot material discharging height: 3600mm×3600mm(height×width)

f) Overall dimension: maximum height 40m, maximum width 30m.

Notes: Relating to Plant Capacity

1 The average moisture content is for surface moisture only.

2 Ambient temperature taken as 15ºC.

3 Material taken as 1600kg per cu.m.

4 Capacities include filler and bitumen.

5 Aggregate feed to plant is in correct proportion required for mix specifications.

6 Filler density 1120kg per cu.m

7 Aggregate is non-porous and not excessively flaky.

8 Altitude 1500m above sea level.
