Specifications
Brand Name :
CINACHARM
Model Number :
PLD1600 aggregate batching machine
Certification :
CE ISO BV SGS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
55 sets per month
Delivery Time :
5 working days after we got advanced payment
Packaging Details :
Covered by plastic
Item :
PLD1600 aggregate batching machine
Model :
PLD1600 aggregate batching machine
Weighing bucket capacity(L) :
1600L
Capacity of storage hopper(m³) :
2*5
Theoretical productivity(m³/h) :
75m3/h
Accuracy of batching :
±2%
Max. Weighing (kg) :
3000
No. of Aggregate Kinds :
3
Belt conveyor speed(m/s) :
1.4
Power(kw) :
3*5.5
Description

pld1600 High Quality automatic Batcher Machine High accuracy PLD1600 aggregate batching machine for concrete plant

pld1600 three bins concrete aggregate machine

Concrete batching machine is used for the aggregates batching for concrete mixing station. The aggregates can be 2-4 types, such as coarse stone, fine stone, sand and others. The proportion of each aggregate is weighed automatically controlled by microcomputer. There are hopper cumulative weighing, belt cumulative weighing and separated hopper weighing
Model No.
PLD600
PLD800
PLD1200
PLD1600
PLD2400
PLD3200
PLD4800
Weighing bucket capacity(L)
600L
800L
1200L
1600L
4*1200L
4*1500L
4*2000L
Capacity of storage hopper(m³)
2*1.4
2*2
2*3.5
2*5
4*15
4*18
4*23
Theoretical productivity(m³/h)
18
48
56
75
120
160
180
Accuracy of batching
±2%
±2%
±2%
±2%
±2%
±2%
±2%
Max. Weighing (kg)
1500
2000
3000
3000
4000
5000
8000
Belt conveyor speed(m/s)
1.25
1.25
1.25
1.4
1.25
1.4
1.25
Power(kw)
3*3
3*2.2
3*3
3*5.5
11
15
18.5

pld1600 three bins hopper concrete batch machine

PLD1600 batching machine is small automatic concrete batching equipment, which can be combined with cement silos. PLD1600 adopts imported sensors, which is quick to response and accurate; the single-hopper modular design is flexible for installation. The weighing capacity is 1600L, the batching accuracy is ±2%, production capacity is 80m³/h. PLD1600 batching machine is ideal concrete or brick aggregate batching equipment.
