PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
Specifications
Brand Name :
CINACHARM
Model Number :
PLD800
Certification :
CE ISO BV SGS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
3 days after we got the payment
Packaging Details :
China Standard Package
Item :
Concrete batcher
Model :
PLD800
Capacity :
48m3/h
Weighing hopper :
0.8m3
Material hopper :
3.2m3*2
Batching accuracy :
±2%
Amount of batching aggregate :
2
Charging height :
2840mm
Description

Aggregate Batcher PLD 800 Concrete Batcher Price Aggregate Batcher PLD1200 concrete mixing plant

This product High precision PLD800 PLD1200 concrete batching machine which is applicable to large or medium-sized hydropower project,construction site and concrete precast part factory,and it is the ideal equipment to improve production efficiency,to low the work force and to keep the concrete good quality.

Technical Parameter of High precision PLD800 concrete batching machine :

Model PLD800 with two storage bins
Weighing hopper 0.8m3
Material hopper 3.2m3*2
Productivity 48m3/h
Batching accuracy ±2%
Amount of batching aggregate 2
Charging height 2840mm
Power 4kw*3
Outline dimension(L*W*H) 6200*1900*2840mm
Weight 2050kg

I. Introduction

1.This batching machine is part of concrete batching plant which is applied with JS/JSS500 concrete mixer,it’s ideal concrete equipment for building project,building ground,and precast product factory.

2.The machine is composed of feeding system,weighing system and electrical system.The main parts:conveyor and hopper,conveyor is a belt feeder,with a precisely weighing system(control level and singal sensor).

Model No.
PLD600
PLD800
PLD1200
PLD1600
PLD2400
PLD3200
PLD4800
Weighing bucket capacity(L)
600L
800L
1200L
1600L
4*1200L
4*1500L
4*2000L
Capacity of storage hopper(m³)
2*1.4
2*2
2*3.5
2*5
4*15
4*18
4*23
Theoretical productivity(m³/h)
18
48
56
75
120
160
180
Accuracy of batching
±2%
±2%
±2%
±2%
±2%
±2%
±2%
Max. Weighing (kg)
1500
2000
3000
3000
4000
5000
8000
Belt conveyor speed(m/s)
1.25
1.25
1.25
1.4
1.25
1.4
1.25
Power(kw)
3*3
3*2.2
3*3
3*5.5
11
15
18.5

PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site

PLD 800 Concrete Aggregate Batching Machine High Precision For Construction Site
