Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant
Specifications
Brand Name :
Cinacharm
Model Number :
YHZS50
Certification :
CE ISO BV SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 sets per month
Delivery Time :
8-10 days
Packaging Details :
China standard package
Product name :
High productivity cement mini YHZS50 concrete mixing plant
Capacity :
50m3/h
Applicable industries :
Manufacturing Plant
Control system :
Automatic Computer Control
Mixer :
JS1000 Concrete Mixer
Batching machine :
PLD1600 Batching Machine
Cement silo :
50t/100t/150t.customized
Weight :
Based,According to different model
Description

hzs60 small concrete batching plant with cement silo

Production Description:

HZS 25 mini mix concrete batching plant for sale with high quality is a combined device used for mixing concrete. Because of its mechanization, high degree of automation, so the productivity is also high, and to ensure the quality of concrete and save cement, commonly used in concrete engineering, long construction period, the site concentration of large and medium-sized water conservancy and electric power engineering, bridge etc.

Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant

Model HZS25 HZS35 HZS50 HZS60 HZS75 HZS90 HZS120 HZS150 HZS180
Discharging Capacity (L) 500 750 1000 1000 1500 1500 2000 2500 3000
Charging Capacity(L) 800 1200 1600 1600 2400 2400 3200 4000 4800
Maximum Productivity(m³/h) 25 35 50 60 75 90 120 150 180
Charging Model Skip Hopper Skip Hopper Skip Hopper belt conveyor Skip Hopper belt conveyor belt conveyor belt conveyor belt conveyor
Standard Discharging Height(m) 1.5~3.8 2~4.2 4.2 4.2 4.2 4.2 3.8~4.5 4.5 4.5
Number of Species of Aggregate 2~3 2~3 3~4 3~4 3~4 4 4 4 4
Maximum Aggregate Size(mm) ≤60mm ≤80mm ≤80mm ≤80mm ≤80mm ≤80mm ≤120mm ≤150mm ≤180mm
Cement/Powder Silo Capacity(set) 1×100T 2×100T 3×100T 3×100T 3×100T 3×100T 4×100T or 200T 4×200T 4×200T
Mixing Cycle Time(s) 72 60 60 60 60 60 60 30 30
Total Installed Capacity(kw) 60 78.5 111 145 110 198.06 210 230 288

Hydraulic Hopper Hzs60 1000L Small Concrete Mixing Plant

FAQ
Q1. How about your company's service, especially after-sale service?

A: ZhengzhouChangli machinery have been in this field for nearly 32 years and have strong production and distribution capability, we can satisfy your demand within15 days. We always do our best to solve any problems and put customer's interests in the first place.

Q2: Do you think where are your advantages?

manufacturer machinery as one of the professional suppliers , most of our products are produced by ourselves, which can guarantee the price and quality.

Q3:Can you sent me some wearing parts?

A:Yes, For some common wearing parts,we will send you freely.

Q4: What is the delivery time?

A: 3-15days after receiving advance payment.

Q5:What paymet terms you use?

Answer:Usually the world most common used T/T,L/C ,etc.
