High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
Specifications
Certification :
UL/cUL Class B/F/H, VDE, CQC
Efficiency :
Up to 98%
Model Number :
E250
Output Voltage :
24-600KV and can be Customized
Price :
＄63.5-89.8/pieces
Insulation Class :
Class F
Supply Ability :
10000pcs
MOQ :
1K
Delivery Time :
7-14 work days (Negotiable)
Product Size :
1000*800*1800mm
Payment Terms :
T/T
Place of Origin :
China
Power Factor :
98%
Brand Name :
CHIPSEN
Rated Capacity :
20KVA
Description
High Power Low Noise E250 Three Phase Transformer Stable Efficient For Machinery
Stable and efficient three-phase laminated power transformer designed for industrial machinery applications.
Product Overview
The E250 Custom Transformer is a three-phase laminated power transformer designed for voltage conversion, electrical isolation, auxiliary power, and industrial power distribution at 50 Hz or 60 Hz.
The product shown uses three separate phase windings installed on a common laminated magnetic core. Heavy steel clamping channels and a bolted open-frame structure provide mechanical support and chassis-mounting points.
Available Configurations
  • Three-phase isolation transformer
  • Three-phase step-down transformer
  • Three-phase step-up transformer
  • Three-phase control transformer
  • Three-phase rectifier transformer
  • Three-phase autotransformer
  • Multiple-secondary transformer
  • Delta-to-star transformer
  • Star-to-delta transformer
  • Customer-defined phase-shifting transformer
Application Specifications
The following values represent common project-discussion ranges used by international buyers when evaluating an E250 three-phase laminated power transformer.
Industry Typical Application Primary Voltage Secondary Voltage Capacity Range
Industrial Control Cabinets Main isolation, control power, PLC supply, contactor circuits 380-480 VAC 24-400 VAC 1-30 kVA
Industrial Machinery CNC machines, pumps, compressors, packaging lines 380-480 VAC 200-415 VAC 2-30 kVA
Motor Drives and VFD Systems Input isolation, drive supply, harmonic mitigation 380-600 VAC 200-480 VAC 3-50 kVA
UPS and Data Center Input isolation, bypass supply, voltage conversion 380-480 VAC 208-415 VAC 3-50 kVA
Solar and Energy Storage Inverter input/output isolation, PCS auxiliary distribution 380-600 VAC 208-415 VAC 3-50 kVA
EV Charging Equipment Input isolation, voltage conversion, charger cabinet supply 380-480 VAC 208-480 VAC 3-50 kVA
All values above are typical buyer inquiry references. Final ratings must be confirmed through the approved customer specification drawing and sample-validation process.
Product Construction
Product Platform E250 custom three-phase transformer
Magnetic Structure Three-limb laminated steel core
Winding Arrangement One primary and secondary phase set on each core limb
Transformer Type Isolation, step-down, step-up, autotransformer or rectifier transformer
Primary Connection Delta, star, zigzag or customer-defined connection
Secondary Connection Delta, star, zigzag, multiple secondary or customer-defined connection
Winding Conductor Enameled copper wire or customer-approved conductor
Mounting Chassis mounting feet, base channels, brackets or customer-defined structure
Terminals Terminal blocks, copper bars, studs, lugs, cables or customer-defined connections
Key Features
  • Three-Phase Power Conversion: Converts three-phase input voltage to required three-phase output voltage
  • Custom Vector Group: Delta, star, zigzag and other connection arrangements available
  • Stable Voltage Regulation: Optimized conductor size, turns ratio, and impedance design
  • High Efficiency Options: Reduced no-load and load losses through optimized design
  • Low Audible Noise Options: Core stacking and mounting structure optimized to reduce transformer hum
  • Balanced Phase Performance: Consistent phase-to-phase voltage and current performance
  • Custom Impedance: Developed according to fault-current limitation and system requirements
  • Multiple Voltage Taps: Primary or secondary taps for voltage adjustment
  • Electrostatic Shielding: Reduces capacitive coupling and common-mode noise
  • Thermal Protection: Embedded sensors, thermostats, and thermal fuses available
  • Industrial Mechanical Construction: Bolted steel clamping channels and reinforced terminal structures
Applications
The E250 Three Phase Transformer can be developed for:
  • Industrial control cabinets and CNC machinery
  • Manufacturing and packaging equipment
  • Pump and compressor systems
  • Variable frequency drives and motor-control centers
  • HVAC and chiller systems
  • UPS equipment and data center power systems
  • Solar inverter systems and energy storage systems
  • EV charging equipment
  • Industrial battery chargers and rectifier systems
  • Medical equipment power distribution
  • Marine electrical systems and transportation power equipment
Quality Assurance
Comprehensive Testing
  • Phase winding resistance and balance testing
  • Voltage ratio and vector-group verification
  • No-load current, voltage, and loss measurements
  • Short-circuit impedance and load loss testing
  • Insulation resistance and dielectric strength testing
  • Applied-voltage and induced-voltage testing
  • Temperature rise and performance validation
Engineering Validation
Samples are evaluated under actual operating conditions including minimum/nominal/maximum input voltage, balanced/unbalanced loads, motor-starting conditions, and maximum ambient temperature.
Why Choose Chipsen
  • Application-Specific Customization: Developed around customer's specific requirements
  • OEM and ODM Support: Complete customization of all components and specifications
  • Drawing and Sample-Based Development: Support for new-product development and second-source assessment
  • Engineering Collaboration: Comprehensive technical review and support
  • Industrial Application Focus: Expertise in industrial power distribution applications
  • Flexible Prototype Support: MOQ of one piece for prototype evaluation
  • Responsive Project Handling: Quotation within 3 days, samples within 7 days
  • Warranty Support: Standard 5-year warranty, up to 20 years for qualified projects
Frequently Asked Questions
Q1: Is E250 a fixed kVA rating?
No. E250 identifies the magnetic and mechanical platform. Actual capacity depends on core stack, conductor size, voltage, frequency, impedance, insulation class, cooling, and allowable temperature rise.
Q2: What information is required for quotation?
Primary voltage, secondary voltage, rated kVA, frequency, vector group, voltage taps, impedance, load type, duty cycle, insulation class, temperature-rise limit, terminals, mounting dimensions, and applicable standard.
Q3: Can primary and secondary voltages be customized?
Yes. Input, output, and tap voltages can be designed according to the required electrical system.
Q4: Can the transformer be designed for both 50 Hz and 60 Hz?
Yes, if the core and windings are specifically designed for both frequencies. A transformer designed only for 60 Hz must not automatically be operated at 50 Hz.
Q5: What is the MOQ?
The MOQ shown for this E250 product is one piece. Final prototype and production quantities depend on materials, construction, and project requirements.
