75x150MM Stainless Steel BTO-10 Diamond Razor Mesh For Security
75x150MM Stainless Steel BTO-10 Diamond Razor Mesh For Security
75x150MM Stainless Steel BTO-10 Diamond Razor Mesh For Security
75x150MM Stainless Steel BTO-10 Diamond Razor Mesh For Security
Specifications
Brand Name :
XR
Model Number :
CRBW
Certification :
CE
Place of Origin :
CHINA
MOQ :
One Piece
Price :
Negotiated
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Pieces Per Week
Delivery Time :
7-10 Days After Get The Payment
Packaging Details :
Water-Proof Plastic Film And Then Pallets
Name :
Welded Razor Wire Mesh
Hole Shape :
Square And Diamond
Type :
Welded
Blade Type :
BTO-22 BTO-10,12,18
Material :
Galvanized And Stainless Steel
Package :
Roll Or Panel
Panel Size :
1.2-2.4M
Benifits :
Impossible To Climb
Description

75x150MM Stainless Steel Welded Razor Wire Rolls And Panels For Security

Welded Razor Wire Mesh Description

Welded razor wire mesh is also known as straight-line razor wire, is by the blade thorn rope straight welded together, is modified according to the welded wire mesh, main function is to guard against theft, climbing and isolation.

Welded Razor Wire Mesh Detailed Specification

1. Hot galvanized sheet and stainless steel sheet 304 316 and so on
2. Galvanized wire(Electro galvanized and hot dipped galvanized)

Blade Specification can be produced according to your request
Reference Number Thickness Wire Dia Barb
Length		 Barb
Width		 Barb
spacing
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 26±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5 28 15 45±1
BTO-30 0.5±0.05 2.5 30 18 45±1
CBT-60 0.5±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.5±0.05 2.5±0.1 65±2 21±1 100±2

Welded Razor Wire Mesh Hole Type And Panel Type

Welded razor wire fence Hole Type

  • Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
  • Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

Panel Specification

Gauge diameter Hole shape Mesh width Suited blade specifications
100mm×100mm Square hole,diamond 1.2m ~ 2.4m BTO-10.12.18.22.28.30, CBT-60.65
100mm×150mm Square hole,diamond 1.2m ~ 2.4m BTO-10.12.18.22.28.30, CBT-60.65
100mm×200mm Square hole,diamond 1.2m ~ 2.4m BTO-10.12.18.22.28.30, CBT-60.65
150mm×300mm Square hole,diamond 1.2m ~ 2.4m BTO-10.12.18.22.28.30, CBT-60.65
other nets hole can according to customers' special needs)


Welded Razor Wire Mesh Surface Treatment

Suface Type Min Max
Hot dipped galvanized 50g/m2 366g/m2
Powder coating 60μm 120μm

Welded Razor Mesh Fence is a new form of razor barbed wire mesh for security. It with practicality blade and the feature looks very beautiful. It can be used for guard net of fence, doors and windows and also can be used in military.

The specification can be designed as the customers’ need.

Welded Razor Wire Mesh Characters

  • 1. it is almost impossible to climb
  • 2. high-strength steel core very difficult to cut off
  • 3. powerful security fence barriers neat appearance
  • 4. no secondary use, so he will not be stolen
  • 5. extremely simple to install, needs three to four to install molding.

75x150MM Stainless Steel BTO-10 Diamond Razor Mesh For Security
