Specifications
Brand Name :
CSQ
Model Number :
51104
Place of Origin :
China
MOQ :
50 pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
50 pcs in 30-40 work days
Delivery Time :
30-40 work days
Packaging Details :
Plastik bag+foam+carton box
Name :
Ceramic Thrust Bearing 51104
Material :
Zirconia Races/Balls+Peek cage
Precision :
P6/ABEC3
Form size :
Ø20×Ø35×110mm
Fixing size :
Ø21×Ø35mm
Pacage :
Foam+cartom box
Description

Ceramic Thrust Bearing 51104 Of Zirconia Races/Balls+Peek Cage With P6/ABEC3 Precision

Description of Ceramic Thrust Bearing 51104 (Zirconia+PEEK):

1. ZrO2 races and balls: Are made by highly purified, sub-micron and after Y2O3-TZP stabled zirconia powder material and are processed by AP (Atmospheric Pressure) sintering and HIP (Hot Isostatic Pressure) sintering technology.

2. PEEK cage: The crown structure cages are adopted British Victrex PEEK material, PEEK has high strength, light body, and similar corrosion resistance to ceramic materials, and has a good resistance to radiation, self-lubricating properties, a high degree of wear resistance and other characteristics.

Performance advantages of Ceramic Thrust Bearing 51104 (Zirconia+PEEK):

Zirconia bearings have a density and linear expansion coefficient close to that of metal steel shafts, high hardness(1300HV5), wear resistance, resistance to various strong acids, strong alkalis, salt corrosion (except hydrofluoric acid), non-magnetic, non-conductive, high temperature resistance(max. 380℃), high operating speed, impact resistance, small starting torque, resistance to dry friction, is one of the most widely used ceramic bearings.

Ceramic Bearings Dimension Reference
Bearings Model Load Rating (Ref.) Load Rating (Ref.) Max Speed (Ref.) Max Speed (Ref.)
Cr(N) Cor(N) Grease (rpm) Oil (rpm)
51104CE 11440 20995 5300 8000

Application of Ceramic Thrust Bearing 51104 (Zirconia+PEEK):

Because of the properties of zirconia and PEEK material, zirconia bearings are suitable for certain vibration and mild impact environment, such as chemical, antimagnetic, semiconductor, medium/low speed and corrosive working environment.
