Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Specifications
Brand Name :
HENGYUAN
Model Number :
99% Alumina Ceramics
Certification :
CE,UL
Place of Origin :
WUXI JIANGSU CHINA
MOQ :
100
Price :
$1-$20
Supply Ability :
5000 PCS/WEEK
Delivery Time :
20 DAYS
Packaging Details :
Carton
Material :
99% Alumina Ceramics
Density :
3.85g/cm³
Flexural Strength :
350 Mpa
Shape :
Customizable
OEM，ODM :
Acceptable
Orgin :
WUXI JIANGSU CHINA
MOQ :
100 PCS
Package :
Carton
Description
Customizable 99% Alumina Ceramics with 350 Mpa Flexural Strength
Product Specifications
Attribute Value
Material 99% Alumina Ceramics
Density 3.85g/cm³
Flexural Strength 350 Mpa
Shape Customizable
OEM/ODM Acceptable
Origin Wuxi Jiangsu, China
MOQ 100 PCS
Package Carton
Product Description

Alumina ceramic is an advanced ceramic material primarily composed of Al2O3, offering exceptional performance characteristics for demanding industrial applications. This 99% alumina ceramic variant provides superior mechanical strength, high temperature resistance, excellent corrosion resistance, and outstanding wear resistance.

Widely used across multiple industries including electronics, textiles, chemicals, construction, and aerospace, alumina ceramics represent one of the most versatile and widely produced oxide ceramic materials available today.

Technical Comparison
Material Unit A95% Alumina Ceramics A97% Alumina Ceramics A99% Alumina Ceramics A99.7% Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric Constant εr 10 10 10 10
Product Gallery
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
Customized 99% Oxide Alumina Based Ceramics Parts Tube For Aerospace Electronics
