Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
Specifications
Brand Name :
HENGYUAN
Model Number :
95% Alumina Ceramics
Certification :
CE,UL
Place of Origin :
WUXI JIANGSU CHINA
MOQ :
100
Price :
$1-$20
Payment Terms :
L/C, T/T
Supply Ability :
5000 PCS/WEEK
Delivery Time :
20 DAYS
Packaging Details :
Carton
Material :
95% Alumina Ceramics
Color :
White
Density :
3.6g/cm³
Working Temperature :
1600℃
OEM，ODM :
Acceptable
Orgin :
WUXI JIANGSU CHINA
MOQ :
100 PCS
Package :
Carton
Description
95% Alumina Ceramics High Insulation And Heat Resistance 1600℃ For Precision Engineering
Product Specifications
Attribute Value
Material 95% Alumina Ceramics
Color White
Density 3.6g/cm³
Working Temperature 1600℃
OEM/ODM Acceptable
Origin Wuxi Jiangsu, China
MOQ 100 PCS
Package Carton
Product Description
Alumina ceramic parts are widely used in electrical appliances, petrochemical, machinery, textiles, automobiles and other industries. Alumina ceramics are currently divided into two types: high purity type and ordinary type. When the content of alumina ceramics is below 99%, it appears pure white. When the content reaches 99% and above, the color of the ceramic is typically light yellow.
Technical Properties Comparison
Material Unit A95% Alumina Ceramics A97% Alumina Ceramics A99% Alumina Ceramics A99.7% Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric constant εr 10 10 10 10
Product Images
Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering Machined 95% Nonporous Alumina Based Ceramics Tubes For Precision Engineering
