Specifications
Brand Name :
HENGYUAN
Model Number :
99% Alumina Ceramics
Certification :
CE,UL
Place of Origin :
WUXI JIANGSU CHINA
MOQ :
100
Price :
$1-$20
Supply Ability :
5000 PCS/WEEK
Delivery Time :
20 DAYS
Packaging Details :
Carton
Material :
99% Alumina Ceramics
Density :
3.85g/cm³
Flexural Strength :
350 Mpa
color :
White or yellow
OEM，ODM :
Acceptable
Orgin :
WUXI JIANGSU CHINA
MOQ :
100 PCS
Package :
Carton
Description
High Purity Hardness 99% Alumina Ceramics Parts
Customizable Specifications in White or Yellow
Product Attributes
Attribute Value
Material 99% Alumina Ceramics
Density 3.85g/cm³
Flexural Strength 350 Mpa
Color White or yellow
OEM/ODM Acceptable
Origin Wuxi Jiangsu, China
MOQ 100 PCS
Package Carton
Product Description

HENGYUAN alumina ceramics are manufactured from Al₂O₃ synthetic raw materials with aluminum concentrations ranging from 95% to 99.7%. These ceramics demonstrate exceptional stability and corrosion resistance at high temperatures up to 1650°C.

Key Advantages
  • High mechanical hardness
  • Superior strength characteristics
  • Excellent electrical insulation properties
  • Outstanding corrosion resistance
Technical Specifications
Material Unit A95% Alumina Ceramics A97% Alumina Ceramics A99% Alumina Ceramics A99.7% Alumina Ceramics
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric Constant εr 10 10 10 10
Product Gallery
